ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT

Basic Information
Place of Origin: China
Brand Name: supreme
Certification: CE
Model Number: MQ320-Y
Minimum Order Quantity: 1
Price: Negotiated
Packaging Details: Seaworthy package
Delivery Time: 20-30 working days
Payment Terms: L/C, T/T
Supply Ability: 30-40sets/month
Detail Information
Material: Blank Adhesive Label Paper Slitting Speed: 120m/m
Web Guide: Yes Color Track: No
Color: Customized Voltage: 220/380V
Unwinding Diameter: 500mm Video: For Video Sent Please Wechat/wa Me:+8618072118971
Language: Can Customized Into Client Regular Language For Easy Operations Product Name: ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT
Note: Because Of Upgraded And Development, Above Datasheet Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company Note: Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company

Product Description

ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT


MQ320-Y Rotary Blank Label Die Cuting Machine With Slitter is a new machinery which research and development for the clients who have Single product structure, it has the function of high precision rotary die cutting station and slitting station, optional for turret rewinding into 2 inch,1.5inch even 1 inch air shaft, it is also work for the blank label laminating.

1:Auto meter/number counting, auto stopping

2:Web guide by photoelectric eye

3: It has the characteristics of compact structure, fast speed, high efficiency, easy operation, accurate slitting, stable operation and so on.



Standard:

1:Rotary die cutting station

2:Slitting station with 8 sets round knife

3:1 pcs 3 inch unwinding air shaft+1 pcs rewinding air shaft+2 pcs 1.5/1/2inch air shaft. (Automatic inflation)

4:meter/number counter.

5:web guide 2 pcs right and left for material

6:1 magnetic brake, 3 pcs magnetic clutch

7:Fan blower for blowing away the waste

8:Main motor

9:Inverter

10: Synchronous motor for waste rewinding controlled

Specification:

Machine ModelMQ320-YMQ420-Y
Slitting Speed120m/min120m/min
Die Cutting Speed120m/min120m/min
Max. Web Width320mm420mm
Max. Unwinding Diameter500mm500mm
Max. Rewinding diameter for big roll500mm500mm
Max. Rewinding diameter for small roll350mm350mm
Length of Die Cutting190-476 mm190-476mm
Dimensions1700*1000*1600mm1800*1300*1700mm
Main motor1.5 KW2.2KW
Voltage220V/380V220V/380V
Min. Slitting width16mm16mm
Machine weight600 kgs800 kgs


About us:
Professionally research and development in label flexographic printing machine, label die cutting machine, label slitting machine and Some other auxiliary equipment, We focus on talents and technological innovation, Adhere to the development strategy of "technical innovation, national brand", making the company a leader in the production line of label machinery.
Honesty, high quality, and service are our business tenet. Forge ahead, pragmatic and efficient are our corporate spirit. We research and manufacture various types of label machines, and welcome all new and old customers and friends to visit!



Support and Services:

ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT Technical Support and Services

We provide technical support and services for ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT. Our team of experienced technicians and engineers are available to help you with any questions or issues you may have. We offer a wide range of services such as installation, maintenance, troubleshooting, and repairs. In addition, we offer training and consulting to ensure that your machinery is running at its best.

At our facility, we provide a full range of services for ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT. Our team of technicians and engineers are available to help you with any questions or issues you may have. From installation to maintenance, our team is fully equipped and ready to assist you.

Our goal is to provide the best technical support and services for ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT. Our team of experts is available to answer any questions or concerns you may have. We take pride in providing quality service, and we are committed to ensuring your satisfaction.

Packing and Shipping:

Packaging and Shipping

ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT is packaged carefully to ensure it arrives safely and in excellent condition. The machines are fully assembled, and then wrapped in film then packed with the fumigation wooden box.

Machines are shipped via air or sea freight, depending on the customer’s preference.

FAQ:

Q: What is the Brand Name of ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT?
A: The Brand Name is Supreme.
Q: What is the Model Number of ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT?
A: The Model Number is MQ-Y.
Q: Where is the Place of Origin of ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT?
A: The Place of Origin is China.
Q: What is the Certification of ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT?
A: The Certification is CE.
Q: What is the Minimum Order Quantity of ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT?
A: The Minimum Order Quantity is 1.
ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT 0ROTARY AUTOMATIC ADHESIVE STICKER LABEL DIE CUTTING SLITTING MACHINE WITH DIE CUT UNIT 1
