SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION

Basic Information
Place of Origin: China
Brand Name: supreme
Certification: CE
Model Number: MQ-YIIE
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: fumigation wooden box
Delivery Time: 30-60 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 20set/month
Detail Information
Video: For Video Sent Please Wechat/wa Me:+8618072118971 Language: Can Customized Into Client Regular Language For Easy Operations
Product Name: SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION Note: Because Of Upgraded And Development, Above Datasheet Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company
Note: Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company

Product Description

SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION



Features:
Intermittent semi rotary die-cutting is a new machining process that is equipped with a servo motor motion control system and color register sensors to arrange high-precision rotary die-cutting systems.
The new processing concept is a feature of this machine, without the need to replace different specifications of magnetic cylinders, only the mold needs to be replaced. It saves time and the cost of making cutting tools. This machine is suitable for pre printing labels. Unwinding, rotary die-cutting, slitting, and rewinding are completed in one process. It can operate in both semi rotary mode and full rotary mode. This machine has the characteristics of compact structure, fast speed, high efficiency, convenient operation, accurate cutting, and smooth operation.



2. Main Technical Parameters:



Slitting speed 120m/min
Die-cutting speed 50m/min (intermittent)
120m/min (full-rotary)
Max web width 350mm
Max unwinding diameter 600 mm
Max rewinding diameter 600 mm
Die cutting length 480mm (intermittent)
570mm (full rotary)
Machine size 2200* 1300* 1500mm
Machine weight 1600kgs
Voltage 380V, 3P
Power 15KW
Standard magnetic cylinder 150T(480mm)
Slitting width 12-350mm
Die cutting precision +-0.15mm



Machine details:

1:web guide

SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION 0

2:Servo motor:

SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION 1

3:slitting part:

SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION 2

4:touch screen:

SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION 3

5:die cutting station:

SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION 4

6:samples:

SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION 5

Support and Services:

SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION Technical Support and Services

We provide technical support and services for SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION. Our team of experienced technicians and engineers are available to help you with any questions or issues you may have. We offer a wide range of services such as installation, maintenance, troubleshooting, and repairs. In addition, we offer training and consulting to ensure that your machinery is running at its best.

At our facility, we provide a full range of services for SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION. Our team of technicians and engineers are available to help you with any questions or issues you may have. From installation to maintenance, our team is fully equipped and ready to assist you.

Our goal is to provide the best technical support and services for SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION. Our team of experts is available to answer any questions or concerns you may have. We take pride in providing quality service, and we are committed to ensuring your satisfaction.

Packing and Shipping:

Packaging and Shipping

SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION is packaged carefully to ensure it arrives safely and in excellent condition. The machines are fully assembled, and then wrapped in film then packed with the fumigation wooden box.

Machines are shipped via air or sea freight, depending on the customer’s preference.

FAQ:

Q: What is the Brand Name of SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION?
A: The Brand Name is Supreme.
Q: What is the Model Number of SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION?
A: The Model Number is MQ-YIIE.
Q: Where is the Place of Origin of SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION?
A: The Place of Origin is China.
Q: What is the Certification of SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION?
A: The Certification is CE.
Q: What is the Minimum Order Quantity of SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION?
A: The Minimum Order Quantity is 1.

SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION 6SEMI ROTRAY INTERMITTENT DIE CUTTING SNOWBALL TYPE WASTE REWINDING DEVICE WITH SLITTING STATION TURRET REWINDING OPTION 7
