| Place of Origin: | China |
|---|---|
| Brand Name: | supreme |
| Certification: | CE |
| Model Number: | RY-5320L |
| Minimum Order Quantity: | 1 |
| Price: | negotiation |
| Packaging Details: | fumigation wooden box |
| Delivery Time: | 30-60 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 20set/month |
| Video: | For Video Sent Please Wechat/wa Me:+8618072118971 | Language: | Can Customized Into Client Regular Language For Easy Operations |
|---|---|---|---|
| Product Name: | SINGLE STATION ROTARY DIE CUTTING FLEXO PRINTING MACHINE IMPORTED VARIABLE FREQUENCY STEPLESS SPEED REGULATION 380V 50HZ | Note: | Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company |
SINGLE STATION ROTARY DIE CUTTING FLEXO PRINTING MACHINE IMPORTED VARIABLE FREQUENCY STEPLESS SPEED REGULATION 380V 50HZ
http://www.youtube.com/@labelturretrewindingmachinery
main features
1. The main motor adopts imported variable frequency stepless speed regulation.
2. The unwinding and rewinding of materials are both controlled by magnetic powder brakes and clutches. Constant tension control
3. The feeding device is controlled by an automatic deviation correction sensor.
4. The ceramic Anilox has the characteristics of long service life, wear resistance and corrosion resistance, which is very beneficial to reduce the number of replacement of the Anilox and improve the printing efficiency.
5. The printing unit adopts 360 degree circumferential plate adjustment. Each printing unit can be individually gear closed or loosened to allow other printing units to continue printing.
6. Each printing unit is equipped with 1 infrared drying device
7. The infrared drying devices of each printing unit can be interchanged with UV devices.
8. The discharge and winding devices adopt an air expansion air shaft
9. When parking, the ink roller can automatically detach and rotate at low speed to prevent ink from drying.
Main technical parameters:
| Printing speed | 0-100 meters/minute |
| Colors | 5 |
| Maximum width of web paper | 320mm |
| Maximum printing width | 310mm |
| Maximum diameter of unwinding | 1000mm |
| Maximum diameter of winding | 600mm |
| Printing perimeter | 175-430mm |
| Drying unit | UV5 group |
| Dimensions | 5m (length) * 1.5m (width) * 2.5m (height) |
| Machine weighs | approximately 3500kg |
We provide technical support and services for SINGLE STATION ROTARY DIE CUTTING FLEXO PRINTING MACHINE IMPORTED VARIABLE FREQUENCY STEPLESS SPEED REGULATION 380V 50HZ. Our team of experienced technicians and engineers are available to help you with any questions or issues you may have. We offer a wide range of services such as installation, maintenance, troubleshooting, and repairs. In addition, we offer training and consulting to ensure that your machinery is running at its best.
At our facility, we provide a full range of services for SINGLE STATION ROTARY DIE CUTTING FLEXO PRINTING MACHINE IMPORTED VARIABLE FREQUENCY STEPLESS SPEED REGULATION 380V 50HZ. Our team of technicians and engineers are available to help you with any questions or issues you may have. From installation to maintenance, our team is fully equipped and ready to assist you.
Our goal is to provide the best technical support and services for SINGLE STATION ROTARY DIE CUTTING FLEXO PRINTING MACHINE IMPORTED VARIABLE FREQUENCY STEPLESS SPEED REGULATION 380V 50HZ. Our team of experts is available to answer any questions or concerns you may have. We take pride in providing quality service, and we are committed to ensuring your satisfaction.
SINGLE STATION ROTARY DIE CUTTING FLEXO PRINTING MACHINE IMPORTED VARIABLE FREQUENCY STEPLESS SPEED REGULATION 380V 50HZ is packaged carefully to ensure it arrives safely and in excellent condition. The machines are fully assembled, and then wrapped in film then packed with the fumigation wooden box.
Machines are shipped via air or sea freight, depending on the customer’s preference.
