AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO

Basic Information
Place of Origin: China
Brand Name: supreme
Certification: CE
Model Number: FQ-800/1100/1300-B
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: fumigation wooden box
Delivery Time: 30-60 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 20set/month
Detail Information
Video: For Video Sent Please Wechat/wa Me:+8618072118971 Language: Can Customized Into Client Regular Language For Easy Operations
Product Name: AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO Note: Because Of Upgraded And Development, Above Datasheet And Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company

Product Description

AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO
https://www.youtube.com/@labelturretrewindingmachinery
Optional: 1:Slip shaft 2:CCD web guide(printed material) 3:shaft-less unwinding

Scope of application:
Machine suitable for many kinds of jumbo roll slitting. Such as 10g/m2~200g/m2 paper(Straw paper, coated paper, coated paper),PET,PVC,aluminum-plastic composite, plastic film etc slitting &rewinding.
Performances and features

1:Machine use servo three motor synchronize control, auto tape tension,center and surface rewinding together;

2:Machine use frequency adjust speed, keep stable running when speed up;

3:auto counter quantity, auto fixed length, auto machine stop when had alarm , auto tension control etc function.

4:Feeding roll use air shaft use 3#(76mm paper tube core)

5:Rewinding use photocell control edge position control way

6:Circular knife slitting waste edge of roll, and it’s auto let out by fan

7:Automatic air shaft/ Hydraulic shaftness unwinding part



Technical data
ModelB-800/1100/1300
Max web width800mm/1100/1300mm
Max unwider diameter1400mm
Max rewinding diameter600mm
Min rewinder web width5mm/7mm/7mm
Slitting speed30-400m/min
Precision of slitting+-0.2mm
Cutting thickness10-500gsm
Total power18kw/18kw/21kw
Machine weight3000kg/3700kg/4300kg
Machine size

3500*2300*1650mm
3500*2800*1650mm
3500*3200*1650mm



About us:
Professionally research and development in tipping paper flexographic printing machine, tipping paper slitting machine and Some other auxiliary equipment, We focus on talents and technological innovation, Adhere to the development strategy of "technical innovation, national brand", making the company a leader in the production line of tipping paper machinery.
Honesty, high quality, and service are our business tenet. Forge ahead, pragmatic and efficient are our corporate spirit. We research and manufacture various types of tipping paper machines, and welcome all new and old customers and friends to visit!


Because of upgraded and development, above datasheet just for reference, for the newest machinery, please enquiry our company. The finally interpretation is owned by our company


Support and Services:

AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO Technical Support and Services

We provide technical support and services for AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO. Our team of experienced technicians and engineers are available to help you with any questions or issues you may have. We offer a wide range of services such as installation, maintenance, troubleshooting, and repairs. In addition, we offer training and consulting to ensure that your machinery is running at its best.

At our facility, we provide a full range of services for AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO. Our team of technicians and engineers are available to help you with any questions or issues you may have. From installation to maintenance, our team is fully equipped and ready to assist you.

Our goal is to provide the best technical support and services for AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO. Our team of experts is available to answer any questions or concerns you may have. We take pride in providing quality service, and we are committed to ensuring your satisfaction.

Packing and Shipping:

Packaging and Shipping

AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO is packaged carefully to ensure it arrives safely and in excellent condition. The machines are fully assembled, and then wrapped in film then packed with the fumigation wooden box.

Machines are shipped via air or sea freight, depending on the customer’s preference.

FAQ:

Q: What is the Brand Name of AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO?
A: The Brand Name is Supreme.
Q: What is the Model Number of AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO?
A: The Model Number is B.
Q: Where is the Place of Origin of AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO?
A: The Place of Origin is China.
Q: What is the Certification of AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO?
A: The Certification is CE.
Q: What is the Minimum Order Quantity of AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO?
A: The Minimum Order Quantity is 1.
AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO 0AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO 1AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO 2AUTOMATIC SURFACE ROLL SLITTING MACHINE SLIP SHAFT CCD WEB GUIDE(PRINTED MATERIAL) SHAFT-LESS UNWINDING 400M/MIN SERVO 3
