FULL/SEMI INTERMITTENT ROTARY/MARK ANDY/OMIT/NEIL PETER FLEXO PRINTING/SLITTING MACHINERY ONLINE TURRET REWINDER No Glue

Basic Information
Place of Origin: China
Brand Name: Supreme
Certification: CE
Model Number: SZ-B
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: fumigation wooden box
Delivery Time: 50-60 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30sets/month
Detail Information
Applications: Full Rotary/semi Intermittent Rotary/Mark Andy/Omit/Neil Peter Flexo Printing/slitting Machinery Packaging: Wooden Box Fumigations
Design: Self Devolopment And Patented Product Name: FULL/SEMI INTERMITTENT ROTARY/MARK ANDY/OMIT/NEIL PETER FLEXO PRINTING/SLITTING MACHINERY ONLINE TURRET REWINDER No Glue
Color: Customized Advantage: 1 Inch, 1.5 Inch, 40mm, 3 Inch Auto Inflatable Air Shaft
Voltage: 220V/380V Video: For Video Sent Please Wechat/wa Me:+8618072118971
Language: Can Customized Into Client Regular Language For Easy Operations Note: Because Of Upgraded And Development, Above Datasheet Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company
Note: Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company

Product Description

FULL/SEMI INTERMITTENT ROTARY/MARK ANDY/OMIT/NEIL PETER FLEXO PRINTING/SLITTING MACHINERY ONLINE TURRET REWINDER No Glue

Product Description:

The product features three parts with different functions: unwinding, slitting and rewinding.

For the unwinding part, it can have a 3-inch air shaft with one piece and an auto tension controller. Web guidance could be delivered by the accompaniment, too.

The slitting part consists of 8 pieces of upper knives, 8 pieces of bottom knives, wheels for left and right hand adjustment, number counting photo-eyes, vacuum waste absorption, and material pulling traction roller using a servo motor.

In the rewinding part, an auto turret rewinding system with a servo motor is equipped, followed by an air shaft with 1 inch or 1.5 inch and two pieces, auto inflation, no glue system, auto cutting system, auto labeling system, auto paper core feeding system and auto unloading(both are optional).



Applications:

Supreme FULL/SEMI INTERMITTENT ROTARY/MARK ANDY/OMIT/NEIL PETER FLEXO PRINTING/SLITTING MACHINERY ONLINE TURRET REWINDER NO GLUE is a customized label adhesive paper sticker solution, designed with self-development and patent technologies. This machine is certified with CE and is available with a minimum order quantity of 1. It is powered by 220V/380V voltage and comes in different colors as per requirement. The machine is packed in a wooden box fumigation and can be delivered within 50-60 working days. The price of this machine is subjected to negotiation and it is supported with a supply ability of 30 sets/month. The machine is suitable for auto cutting, Label no glue turret slitter rewinder semi auto and other processes.



Customization:

Supreme FULL/SEMI INTERMITTENT ROTARY/MARK ANDY/OMIT/NEIL PETER FLEXO PRINTING/SLITTING MACHINERY ONLINE TURRET REWINDER NO GLUE is customized with CE certification, minimum order quantity of 1 and negotiable price. It is packed in fumigation wooden box and delivered within 50-60 working days after payment through TT or LC. We can supply 30sets/month. The advantages include 1 Inch, 1.5 Inch, 40mm, and 3 Inch Auto Inflatable Air Shaft, and it is a Lable Adhesive Paper Sticker Solution with yes adhesive and size 330/450/570mm. In addition, we are also looking for agents worldwide to promote our product with enviromental protection (no glue no smell) and material saving (save glue cost).



Support and Services:

FULL/SEMI INTERMITTENT ROTARY/MARK ANDY/OMIT/NEIL PETER FLEXO PRINTING/SLITTING MACHINERY ONLINE TURRET REWINDER NO GLUE Technical Support and Service

We provide technical support and services for FULL/SEMI INTERMITTENT ROTARY/MARK ANDY/OMIT/NEIL PETER FLEXO PRINTING/SLITTING MACHINERY ONLINE TURRET REWINDER NO GLUE, including installation, commissioning, maintenance, and repair. Our experienced technicians are available 24/7 to assist in troubleshooting and resolving any issues that may arise.

Our services include a one-year warranty for any parts or components that malfunction due to normal wear and tear. We also offer extended warranties for a nominal fee. In addition, we provide software updates and upgrades to ensure our products remain up-to-date with the latest technologies.

At FULL/SEMI INTERMITTENT ROTARY/MARK ANDY/OMIT/NEIL PETER FLEXO PRINTING/SLITTING MACHINERY ONLINE TURRET REWINDER NO GLUE, we are committed to providing our customers with the highest quality technical support and service. We are dedicated to providing the best solutions for your FULL/SEMI INTERMITTENT ROTARY/MARK ANDY/OMIT/NEIL PETER FLEXO PRINTING/SLITTING MACHINERY ONLINE TURRET REWINDER NO GLUE needs.



Packing and Shipping:

FULL/SEMI INTERMITTENT ROTARY/MARK ANDY/OMIT/NEIL PETER FLEXO PRINTING/SLITTING MACHINERY ONLINE TURRET REWINDER NO GLUE packaging and shipping consists of using high-quality, durable fumigation wooden box and film wrap to ensure the machinery is safe during transit. The boxes are designed to fit the machinery securely and protect it from any impacts that may occur during shipping.

FAQ:

Q1: What is the Brand Name of this product?
A1: The Brand Name of this product is Supreme.
Q2: What is the Model Number of this product?
A2: The Model Number of this product is SZ-B.
Q3: Where is this product from?
A3: This product is from China.
Q4: What is the Certification of this product?
A4: The Certification of this product is CE.
Q5: What is the Minimum Order Quantity?
A5: The Minimum Order Quantity is 1.


Specification:

Machine Model SZ-330B SZ-450B
Max paper feeding 330mm 450mm
Max speed 150m/min 150m/min
Slitting precision +-0.1mm +-0.1mm
Max unwinding diameter 700mm(customized into 1000mm) 700mm
Max rewinding diameter 180mm(customized into 254mm) 180mm
Voltage 220V 1P 50HZ/380V 3P 50HZ 220V 1P 50HZ/380V 3P 50HZ
Total power 6KW 8KW
Machine weight

1000kg



1500kg



Machine size 1500*1200*3000mm 1500*1400*3100



1:Paper core auto feeding system:

2:Auto labeling system:

3:No glue system,auto turret system and auto cutting system:

Machine details:

1:slitting speed:150m/min

2:slitting precision:+-0.1mm

3:paper feeding width max:330mm

4:max unwinding diameter:700mm(customized into 1000mm)

5:max rewinding diameter:180mm(customized into 254mm)

6:machine weight:1000kg

7:machine voltage:220V/380V

8:Total power:6kw

9:machine size:1500*1200*3000mm

FULL/SEMI INTERMITTENT ROTARY/MARK ANDY/OMIT/NEIL PETER FLEXO PRINTING/SLITTING MACHINERY ONLINE TURRET REWINDER No Glue 0FULL/SEMI INTERMITTENT ROTARY/MARK ANDY/OMIT/NEIL PETER FLEXO PRINTING/SLITTING MACHINERY ONLINE TURRET REWINDER No Glue 1
