CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR

Basic Information
Place of Origin: China
Brand Name: Supreme
Certification: CE
Model Number: SZ
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: fumigation wooden box
Delivery Time: 50-60 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30sets/month
Detail Information
Application: Non Glue Auto Labeling And Slitting Machinery For Paper Adhesive Sticker Label Size: 330/450/570mm
Service: OEM/ODM Type: Lable Adhesive Paper Sticker Solution
Adhesive: Yes Material: Paper Adhesive Sticker Label Layers
Advantage: 1 Inch, 1.5 Inch, 40mm, 3 Inch Auto Inflatable Air Shaft Video: For Video Sent Please Wechat/wa Me:+8618072118971
Language: Can Customized Into Client Regular Language For Easy Operations Product Name: CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR
Note: Because Of Upgraded And Development, Above Datasheet Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company Note: Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company

Product Description

CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR

Product Description:

Automatic Turret 4 spindle shafts rewinder is a fully automatic rewinding machine, specially designed for label production. It works together with slitting machine or other multi-functional machines with slitting station, so it can do non-stop rewinding to improve production efficiency.

The Characteristics of Copy Paper Rewinder include:

  • Automatic core loading equipped with a storage tower for small cores.
  • Automatic feeding system equipped with mechanical arm, which can ensure cores to be positioned automatically and accurately onto the rewind shaft.
  • Friendly operation with the PLC and touch screen automatic control system.
  • Automatic gluing for cores(only for glue types machines).
  • 4 spindle automatic turret rewinding.
  • Automatic roll eject system.
  • Automatic labeling as standard (which makes the machine price be very favorable).
  • No changeover times involved other than rewind shaft changeover.
  • It can run at a high speed from 50 to 120 m/min.
  • The double sided heavy machine body can ensure the machine to run stably at high speed.
  • It is equipped with a professional customized turret which is maintenance-free for 10 years.
  • Thanks to the multi-optimized combination of mechanical and electrical, it can carry out single expansion shaft for eight-die rewinding roll without biting the roll.


Applications:

The rewinder, a versatile device, is able to be connected to various types of machines, including rotary die cutting machines, slitting machines, and flexographic printing machines. Furthermore, it comes with a set of quick release air-expansion shafts, available in three sizes: one-inch, one-and-a-half-inch, and two-inch.

With the intelligent rewinding machine, it is easy and convenient to change the size of different reels, as it has a system that will automatically adjust to the new size, significantly reduce manual labor. Thus, moving towards achieving an intelligent production system.



Customization:

Supreme offers customized services for CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR. With brand name Supreme, model number SZ, CE certification and a minimum order quantity of 1, the price is negotiable. Packaging details include fumigation wooden box, and the delivery time is 50-60 working days. Payment terms include TT or LC. We can supply 30 sets/month. The packaging is wooden box fumigations, with voltage options of 220V/380V and size options of 330/450/570mm. The product design is self-development and patented. Our CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR also features semi auto at dual turret slitter and turret rewinder.



Support and Services:

CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR technical support and services include:

  • 24/7 technical support
  • Customized installation and maintenance
  • On-site training and remote diagnostics
  • In-depth troubleshooting and analysis
  • Regular updates and upgrades
  • Product replacement and repair


Packing and Shipping:

CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR packaging and shipping includes:

  • Putting the machinery into a wrap film and packed with fumigation wooden box
  • Labeling the box with shipping mark
  • Ensuring all parts and accessories are included in the box
  • Shipping the box through a reliable delivery service


FAQ:

  • Q: What is the brand name of the CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR?
    A: The brand name is Supreme.
  • Q: What is the model number of the CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR?
    A: The model number is SZ.
  • Q: Where is CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR?
    A: It is manufactured in China.
  • Q: Does CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR have CE certification?
    A: Yes, it has CE certification.
  • Q: What is the minimum order quantity for CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR?
    A: The minimum order quantity is 1.





Standard with the machine:
1. rewinding machine: SZ-330/SZ-450/SZ-570: 1 piece
2. tube delivery rack: 1 piece

3. vibration plate:1 piece
4. Air shaft:SZ-330/SZ-450/SZ-570:12 pieces

5. Tool box: 1 box

6. internal hexagonal wrench:1 set

7: open spanner:10-17:1 group

8: Slotted screwdriver and cross screwdriver: 1piece/each

9: Level adjuster screw: 4 piece

10: circlip plier: 6#: 2 pieces

11:Oil gun: 1 piece

12:magnetic valve:DC24V:2 pieces

13:Relay:DC24V:2pieces

14:encoder:DBS36E-S3AK02000: Germany Sick: 1 piece

15:330/450/570 knife:1 pieces

16:Auto labeling device:1 set



Specification:

Machine Model SZ-330 SZ-450 SZ-570

Max rewinding diameter

(glue type)

350mm 350mm 350mm

Max rewinding diameter

(glue free)

200mm 200mm 200mm
Max Paper feeding 330mm 450mm 570mm
Max rewinding speed 50-120m/min 50-120m/min 50-120m/min
Mini rewinding width 30mm 30mm 30mm
Power source 380V/3P/50HZ 380V/3P/50HZ 380V/3P/50HZ
Power 13 kw 13 kw 13kw
Air source 0.8Mpa 1m3/min 0.8Mpa 1.5m3/min 0.8Mpa 1.5m3/min
Machine Dimensions

2020x2080x2800mm

(glue type)

3700 x2080 x2800

(glue free)

2020x2080x2800mm

(glue type)

3700 x2080 x2800

(glue free)

2020x2200x2800mm

(glue type)

3700 x2200 x2800

(glue free)

Machine weight

2500 kgs (glue type)

3500 kgs (glue free)

2500 kgs (glue type)

3500 kgs (glue free)

2800 kgs (glue type)

3800 kgs (glue free)



Automatic 4 spindles paper non stop label turret slitter rewinder save labor cost and improve efficiency



The advantage of ours machine(finished by glue-less non-stop turret rewinder):

1:No creases 2:Zero waste 3:save glue cost 4:save electricity consumptions PS others:1:Fold on the label 2:4-5 label waste at least



About us:

Professionally research and development in label flexographic printing machine, label die cutting machine, label slitting machine and Some other auxiliary equipment, We focus on talents and technological innovation, Adhere to the development strategy of "technical innovation, national brand", making the company a leader in the production line of label machinery.

Honesty, high quality, and service are our business tenet. Forge ahead, pragmatic and efficient are our corporate spirit. We research and manufacture various types of label machines, and welcome all new and old customers and friends to visit!





Because of upgraded and development, above datasheet just for reference, for the newest machinery, please enquiry our company. The finally interpretation is owned by our company

CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR 1CUSTOMIZED LABLE SOLUTION LABEL NON GLUE NO STOP TURRET SLITTER REWINDER MACHINERY FULL AUTOMATIC 4 SPINDLE 4 SHAFT FOUR 2
