NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING

Basic Information
Place of Origin: China
Brand Name: Supreme
Certification: CE
Model Number: SZ
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: fumigation wooden box
Delivery Time: 50-60 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30sets/month
Detail Information
Application: Non Glue Auto Labeling And Slitting Machinery For Paper Adhesive Sticker Label Design: Self Devolopment And Patented
Voltage: 220V/380V Rewinding Part: AB Turret Graphic Rewinding
Service: OEM/ODM Size: 330/450/570mm
Type: Lable Adhesive Paper Sticker Solution Video: For Video Sent Please Wechat/wa Me:+8618072118971
Language: Can Customized Into Client Regular Language For Easy Operations Product Name: NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING
Note: Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company

Product Description

NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING

http://www.youtube.com/@labelturretrewindingmachinery

Product Description:

Automatic Turret 4 shafts rewinder is a fully automatic rewinding machine, designed to be used in label production. It works together with slitting machine or other multi functional machine with slitting station, which improves the production efficiency without needing to pause the process.

This rewinder has several characteristics which make it advantageous to use. Firstly, it is equipped with automatic core loading and a storage tower for small cores for an easy and accurate loading process. Secondly, it comes with a PLC and touch screen automatic control for friendly operation. Furthermore, it has automatic applying glue for cores and four spindle turret rewinding for efficiency. The machine also comes with an automatic roll eject system and labeling as standard. In addition, it has no changeover times involved, with a high speed reaching from 50 to 120m/min. Lastly, it has a double side heavy machine body for stability in high speed and a large roulette supported by a professional customized turret which is maintenance-free for at least ten years, allowing for single expansion shaft for eight-die rewinding roll without biting the roll.



Applications:

The rewinder can be connected to a variety of machinery, such as rotary die cutting machines, slitters, and flexographic printers. It features an air-expansion shaft in 1-inch, 1.5-inch, and 2-inch sizes, which gives it the ability to quickly exchange and switch between different sizes of reels without needing manual adjustments. This advanced intelligent system helps to reduce labor while improving production efficiency.



Customization:

Supreme SZ NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING , with CE certification, is available with a minimum order quantity of 1. The price is open for negotiation. Packaged in fumigation wooden boxes, it can be delivered within 50-60 working days. Payment terms include TT and LC. There is a supply ability of 30sets/month. This machinery is made with adhesive and can be used for non glue auto labeling and slitting machinery for paper adhesive sticker label. OEM/ODM services are available for this product. Applications include RG-330/450/570 Label Automatic non-stop turret rewinding machine, No glue turret slitter machine price, 4 spindle turret rewinding machine, full rotary/semi intermittent rotary/Mark Andy/Omit/Neil Peter Flexo Printing/slitting Machinery.



Support and Services:

NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING Technical Support and Service

We offer technical support and service for our NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING , including:

  • In-depth product information and user manuals
  • Troubleshooting and repair services
  • On-site installation and maintenance
  • Software updates and upgrades
  • Training courses and seminars
  • Online support and customer service


Packing and Shipping:

Packaging and Shipping for NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING
  • NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING is securely packed and shipped in accordance with industry standards to ensure safe delivery of the product. All materials are wrapped with protective material to prevent damage during transit. The product is then placed inside a fumigation wooden box to protect it from further damage. The outside of box with the shipping mark, then shipping to client workshop


FAQ:

Q1: What is the Brand Name of NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING ?
A1: The Brand Name of NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING is Supreme.
Q2: What is the Model Number of NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING ?
A2: The Model Number of NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING is SZ.
Q3: Where is NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING produced?
A3: NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING is produced in China.
Q4: What is the Certification of NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING ?
A4: The Certification of NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING is CE.
Q5: What is the Minimum Order Quantity of NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING ?
A5: The Minimum Order Quantity of NON GLUE ADHESIVE LABEL PAPER STICKER PROCESS MACHINERY CE CERTIFIED FULLY AUTOMATIC REWINDING MACHINE TURRET SLITTING is 1.


Standard with the machine:
1. rewinding machine: SZ-330/SZ-450/SZ-570: 1 piece
2. tube delivery rack: 1 piece

3. vibration plate:1 piece
4. Air shaft:SZ-330/SZ-450/SZ-570:12 pieces

5. Tool box: 1 box

6. internal hexagonal wrench:1 set

7: open spanner:10-17:1 group

8: Slotted screwdriver and cross screwdriver: 1piece/each

9: Level adjuster screw: 4 piece

10: circlip plier: 6#: 2 pieces

11:Oil gun: 1 piece

12:magnetic valve:DC24V:2 pieces

13:Relay:DC24V:2pieces

14:encoder:DBS36E-S3AK02000: Germany Sick: 1 piece

15:330/450/570 knife:1 pieces

16:Auto labeling device:1 set



Specification:

Machine Model SZ-330 SZ-450 SZ-570

Max rewinding diameter

(glue type)

350mm 350mm 350mm

Max rewinding diameter

(glue free)

200mm 200mm 200mm
Max Paper feeding 330mm 450mm 570mm
Max rewinding speed 50-120m/min 50-120m/min 50-120m/min
Mini rewinding width 30mm 30mm 30mm
Power source 380V/3P/50HZ 380V/3P/50HZ 380V/3P/50HZ
Power 13 kw 13 kw 13kw
Air source 0.8Mpa 1m3/min 0.8Mpa 1.5m3/min 0.8Mpa 1.5m3/min
Machine Dimensions

2020x2080x2800mm

(glue type)

3700 x2080 x2800

(glue free)

2020x2080x2800mm

(glue type)

3700 x2080 x2800

(glue free)

2020x2200x2800mm

(glue type)

3700 x2200 x2800

(glue free)

Machine weight

2500 kgs (glue type)

3500 kgs (glue free)

2500 kgs (glue type)

3500 kgs (glue free)

2800 kgs (glue type)

3800 kgs (glue free)



Automatic 4 spindles paper non stop label turret slitter rewinder save labor cost and improve efficiency



The advantage of ours machine(finished by glue-less non-stop turret rewinder):

1:No creases 2:Zero waste 3:save glue cost 4:save electricity consumptions PS others:1:Fold on the label 2:4-5 label waste at least



About us:

Professionally research and development in label flexographic printing machine, label die cutting machine, label slitting machine and Some other auxiliary equipment, We focus on talents and technological innovation, Adhere to the development strategy of "technical innovation, national brand", making the company a leader in the production line of label machinery.

Honesty, high quality, and service are our business tenet. Forge ahead, pragmatic and efficient are our corporate spirit. We research and manufacture various types of label machines, and welcome all new and old customers and friends to visit!





Because of upgraded and development, above datasheet just for reference, for the newest machinery, please enquiry our company. The finally interpretation is owned by our company
