Rewinding Part: | AB Turret Graphic Rewinding | Service: | OEM/ODM |
---|---|---|---|
Size: | 330/450/570mm | Type: | Lable Adhesive Paper Sticker Solution |
Design: | Self Devolopment And Patented | Adhesive: | Yes |
Video: | For Video Sent Please Wechat/wa Me:+8618072118971 | Language: | Can Customized Into Client Regular Language For Easy Operations |
Product Name: | EFFICIENT LABOR COST REDUCTION DELIVERY IN 50-60 WORKING DAYS WOODEN BOX PACKAGING AUTOMATIC TURRET 4 SHAFTS REWINDER | Note: | Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company |
http://www.youtube.com/@labelturretrewindingmachinery
The Automatic Turret 4 shafts Rewinder is a fully-automatic rewinding machine that is ideal for label production. Complemented with a slitting or multi-functional machine with a slitting station, it can perform continuous rewinding to enhance productivity.
This rewinder features a range of remarkable characteristics. First, it is equipped with an automatic core loading mechanism and a storage tower for small cores. It also incorporates an automated feeding system with a mechanical arm to make sure that the cores are properly positioned on the rewind shaft. Furthermore, it is built with a PLC and touch-screen automated system for more intuitive control. There is also an automated glue (glue-type machine) application for cores, a four-spindle automatic turret rewinding system, an automated roll eject system, and a labeling apparatus. What's more, this machine requires minimal changeover time and can run at a speed between 50 to 120 m/min. Finally, the heavy machine body supports a specialized turret that can be maintenance-free for up to ten years, as well as a multi-optimized mechanical and electrical combination for single-expansion rewinding roll without roll-biting.
The rewinder is versatile. It can be connected to a variety of machines, such as rotary die cutting and slitting machines, or flexographic printing machines. Moreover, it comes with three different sizes of quick release air-expansion shaft, 1-inch, 1.5-inch and 2-inch, which allows for great flexibility and convenience.
The rewinding machine is also designed to optimize productivity. It eliminates the need for manual mechanical adjustment when reel size is changed. Its system automatically adjusts the size, significantly reducing labor costs and allowing for better production efficiency.
EFFICIENT LABOR COST REDUCTION DELIVERY IN 50-60 WORKING DAYS WOODEN BOX PACKAGING AUTOMATIC TURRET 4 SHAFTS REWINDER with Supreme SZ model, manufactured in China, has obtained CE certification. With a minimum order quantity of 1, it is possible to negotiate the price. The packaging details include a fumigation wooden box, and the delivery time is 50-60 working days. Payment terms include TT and LC. The supply ability is 30sets/month and the packaging is wooden box fumigations. This product is a label adhesive paper sticker solution, with 4 shaft turret rewinder and label no glue turret slitter rewinder semi auto. It is a rewinder machine with self-development and patented design.
EFFICIENT LABOR COST REDUCTION DELIVERY IN 50-60 WORKING DAYS WOODEN BOX PACKAGING AUTOMATIC TURRET 4 SHAFTS REWINDER technical support and services provide customers with the best solutions for their needs. Our services include installation, calibration, maintenance, repair, and troubleshooting. We also provide technical assistance for any questions or concerns customers may have. Additionally, we offer training courses to ensure that our customers are up-to-date on the latest technology and industry trends. Our team of highly experienced and knowledgeable technicians are available to help customers get the most out of their equipment and maximize its performance.
Packaging and Shipping for EFFICIENT LABOR COST REDUCTION DELIVERY IN 50-60 WORKING DAYS WOODEN BOX PACKAGING AUTOMATIC TURRET 4 SHAFTS REWINDER:
Standard with the machine:
1. rewinding machine: SZ-330/SZ-450/SZ-570: 1 piece
2. tube delivery rack: 1 piece
3. vibration plate:1 piece
4. Air shaft:SZ-330/SZ-450/SZ-570:12 pieces
5. Tool box: 1 box
6. internal hexagonal wrench:1 set
7: open spanner:10-17:1 group
8: Slotted screwdriver and cross screwdriver: 1piece/each
9: Level adjuster screw: 4 piece
10: circlip plier: 6#: 2 pieces
11:Oil gun: 1 piece
12:magnetic valve:DC24V:2 pieces
13:Relay:DC24V:2pieces
14:encoder:DBS36E-S3AK02000: Germany Sick: 1 piece
15:330/450/570 knife:1 pieces
16:Auto labeling device:1 set
Specification:
Machine Model | SZ-330 | SZ-450 | SZ-570 |
Max rewinding diameter (glue type) |
350mm | 350mm | 350mm |
Max rewinding diameter (glue free) |
200mm | 200mm | 200mm |
Max Paper feeding | 330mm | 450mm | 570mm |
Max rewinding speed | 50-120m/min | 50-120m/min | 50-120m/min |
Mini rewinding width | 30mm | 30mm | 30mm |
Power source | 380V/3P/50HZ | 380V/3P/50HZ | 380V/3P/50HZ |
Power | 13 kw | 13 kw | 13kw |
Air source | 0.8Mpa 1m3/min | 0.8Mpa 1.5m3/min | 0.8Mpa 1.5m3/min |
Machine Dimensions |
2020x2080x2800mm (glue type) 3700 x2080 x2800 (glue free) |
2020x2080x2800mm (glue type) 3700 x2080 x2800 (glue free) |
2020x2200x2800mm (glue type) 3700 x2200 x2800 (glue free) |
Machine weight |
2500 kgs (glue type) 3500 kgs (glue free) |
2500 kgs (glue type) 3500 kgs (glue free) |
2800 kgs (glue type) 3800 kgs (glue free) |
The advantage of ours machine(finished by glue-less non-stop turret rewinder):
1:No creases 2:Zero waste 3:save glue cost 4:save electricity consumptions PS others:1:Fold on the label 2:4-5 label waste at least
About us:
Professionally research and development in label flexographic printing machine, label die cutting machine, label slitting machine and Some other auxiliary equipment, We focus on talents and technological innovation, Adhere to the development strategy of "technical innovation, national brand", making the company a leader in the production line of label machinery.
Honesty, high quality, and service are our business tenet. Forge ahead, pragmatic and efficient are our corporate spirit. We research and manufacture various types of label machines, and welcome all new and old customers and friends to visit!
Because of upgraded and development, above datasheet just for reference, for the newest machinery, please enquiry our company. The finally interpretation is owned by our company
