| Place of Origin: | China |
|---|---|
| Brand Name: | Supreme |
| Certification: | CE |
| Model Number: | SZ |
| Minimum Order Quantity: | 1 |
| Price: | Negotiable |
| Packaging Details: | fumigation wooden box |
| Delivery Time: | 50-60 Working Days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 30sets/month |
| Applications: | Full Rotary/semi Intermittent Rotary/Mark Andy/Omit/Neil Peter Flexo Printing/slitting Machinery | Size: | 330/450/570mm |
|---|---|---|---|
| Adhesive: | Yes | Voltage: | 220V/380V |
| Design: | Self Devolopment And Patented | Advantage: | 1 Inch, 1.5 Inch, 40mm, 3 Inch Auto Inflatable Air Shaft |
| Video: | For Video Sent Please Wechat/wa Me:+8618072118971 | Language: | Can Customized Into Client Regular Language For Easy Operations |
| Product Name: | BOOST PROFITS WITH KEY OF THE PROFIT SAVING LABOR AND GLUE COST NON GLUE AUTO LABELING AND SLITTING MACHINERY NO STOP | Note: | Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company |
http://www.youtube.com/@labelturretrewindingmachinery
The Automatic Turret 4 shafts Rewinder is a fully automatic rewinding machine, and it is usually used for label production. It can be used with a slitting machine or with other multi-functional machine that have a slitting station, enabling non-stop rewinding, increasing production efficiency.
This rewinder has a number of advantageous characteristics, such as an automatic core loading system equipped with a tower for small cores, an automatic feeding system with a mechanical arm to position cores accurately onto the rewind shaft, and a PLC and touch screen control making the operation more convenient. Furthermore, the machine provides automatic glue application to the cores and four spindle automatic turret rewinding; automatic roll eject system, automatic labeling, and no changeover times involved are also standard in the machine, adding to its appeal and making its price very competitive.
It also has a high speed output of 50-120m/min, thanks to the double sided heavy machine body, which keeps it stable at high speed and ensures a durable performance. The combination of mechanical and electrical components also allows for single expansion shafts for eight-die rewinding rolls without biting. Plus, thanks to the large roulette supported by a professional customized turret, it is maintenance-free for ten years.
The rewinder can be connected to many common machines, such as rotary die cutting, slitting and flexographic printing machines. It is specially equipped with a quick-release air-expansion shaft of sizes 1 inch, 1.5 inch and 2 inch. It is superior to manual mechanical adjustment when changing the size of different reels, its system automatically adjusts and regulates the size, thus reducing labor force for intelligent production.
Brand Name: Supreme
Model Number: SZ
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Fumigation Wooden Box
Delivery Time: 50-60 working days
Payment Terms: TT; LC
Supply Ability: 30 sets/month
Adhesive: Yes
Product Name: Label No Glue Turret Slitter Rewinder Semi Auto And Full Automatic Labeling System
Application: Non Glue Auto Labeling And Slitting Machinery For Paper Adhesive Sticker Label
Packaging: Wooden Box Fumigations
Features: 4 2 Shaft Turret Slitter, enviromental protection (no glue no smell), AB turret graphic 4 spindle shaft rewinding machinery.
We provide comprehensive technical support and services for BOOST PROFITS WITH KEY OF THE PROFIT SAVING LABOR AND GLUE COST NON GLUE AUTO LABELING AND SLITTING MACHINERY NO STOP. Our experienced team of engineers and technicians is available to assist you with any questions or concerns you may have. Our services include:
We are committed to providing the highest quality of service and support to our customers. Our team of experts is dedicated to ensuring that your BOOST PROFITS WITH KEY OF THE PROFIT SAVING LABOR AND GLUE COST NON GLUE AUTO LABELING AND SLITTING MACHINERY NO STOP operates at optimal levels. Contact us today for more information.
Packaging and Shipping for BOOST PROFITS WITH KEY OF THE PROFIT SAVING LABOR AND GLUE COST NON GLUE AUTO LABELING AND SLITTING MACHINERY NO STOP:
The BOOST PROFITS WITH KEY OF THE PROFIT SAVING LABOR AND GLUE COST NON GLUE AUTO LABELING AND SLITTING MACHINERY NO STOP is securely packaged in a fumigation wooden box and labeled with the product information. The box is then placed onto a standard pallet and shrink-wrapped for extra protection during transit. The pallet is then loaded onto a truck or cargo plane for delivery to the customer's designated location.
A5: The minimum order quantity is 1.
Standard with the machine:
1. rewinding machine: SZ-330/SZ-450/SZ-570: 1 piece
2. tube delivery rack: 1 piece
3. vibration plate:1 piece
4. Air shaft:SZ-330/SZ-450/SZ-570:12 pieces
5. Tool box: 1 box
6. internal hexagonal wrench:1 set
7: open spanner:10-17:1 group
8: Slotted screwdriver and cross screwdriver: 1piece/each
9: Level adjuster screw: 4 piece
10: circlip plier: 6#: 2 pieces
11:Oil gun: 1 piece
12:magnetic valve:DC24V:2 pieces
13:Relay:DC24V:2pieces
14:encoder:DBS36E-S3AK02000: Germany Sick: 1 piece
15:330/450/570 knife:1 pieces
16:Auto labeling device:1 set
Specification:
| Machine Model | SZ-330 | SZ-450 | SZ-570 |
|
Max rewinding diameter (glue type) |
350mm | 350mm | 350mm |
|
Max rewinding diameter (glue free) |
200mm | 200mm | 200mm |
| Max Paper feeding | 330mm | 450mm | 570mm |
| Max rewinding speed | 50-120m/min | 50-120m/min | 50-120m/min |
| Mini rewinding width | 30mm | 30mm | 30mm |
| Power source | 380V/3P/50HZ | 380V/3P/50HZ | 380V/3P/50HZ |
| Power | 13 kw | 13 kw | 13kw |
| Air source | 0.8Mpa 1m3/min | 0.8Mpa 1.5m3/min | 0.8Mpa 1.5m3/min |
| Machine Dimensions |
2020x2080x2800mm (glue type) 3700 x2080 x2800 (glue free) |
2020x2080x2800mm (glue type) 3700 x2080 x2800 (glue free) |
2020x2200x2800mm (glue type) 3700 x2200 x2800 (glue free) |
| Machine weight |
2500 kgs (glue type) 3500 kgs (glue free) |
2500 kgs (glue type) 3500 kgs (glue free) |
2800 kgs (glue type) 3800 kgs (glue free) |
The advantage of ours machine(finished by glue-less non-stop turret rewinder):
1:No creases 2:Zero waste 3:save glue cost 4:save electricity consumptions PS others:1:Fold on the label 2:4-5 label waste at least
About us:
Professionally research and development in label flexographic printing machine, label die cutting machine, label slitting machine and Some other auxiliary equipment, We focus on talents and technological innovation, Adhere to the development strategy of "technical innovation, national brand", making the company a leader in the production line of label machinery.
Honesty, high quality, and service are our business tenet. Forge ahead, pragmatic and efficient are our corporate spirit. We research and manufacture various types of label machines, and welcome all new and old customers and friends to visit!
Because of upgraded and development, above datasheet just for reference, for the newest machinery, please enquiry our company. The finally interpretation is owned by our company
