INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT

Basic Information
Place of Origin: China
Brand Name: Supreme
Certification: CE
Model Number: SZ
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: fumigation wooden box
Delivery Time: 50-60 Working Days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30sets/month
Detail Information
Material: Paper Adhesive Sticker Label Layers Design: Self Devolopment And Patented
Adhesive: Yes Packaging: Wooden Box Fumigations
Color: Customized Applications: Full Rotary/semi Intermittent Rotary/Mark Andy/Omit/Neil Peter Flexo Printing/slitting Machinery
Video: For Video Sent Please Wechat/wa Me:+8618072118971 Language: Can Customized Into Client Regular Language For Easy Operations
Product Name: INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT Note: Because Of Upgraded And Development, Above Datasheet Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company
Note: Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company

Product Description

INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT

Product Description:

The Automatic Turret 4 shafts Rewinder is an ideal machine for optimizing label production. It is used together with a slitting machine or other multi-functional machine that comes with a slitting station to allow for non-stop rewinding.

Characteristics of this Copy Paper Rewinder include an automatic core loading feature with a storage tower for small cores, a PLC and touch screen for automatic control and friendly operation, automatic glue application (glue type machine) to the cores, 4 spindle automatic turret rewinding, an automatic roll eject system and automatic labeling as a standard.

In addition, the machine has no changeover times involved (other than rewind shaft changeover), is capable of a high speed operation with a rate of 50-120m/min, feature a double side heavy machine body to ensure machine running stability in high speed, a large professionally customized turret that is maintenance-free for ten years and a multi-optimized combination of mechanical and electrical systems allowing for single expansion shaft for eight-die rewinding roll without biting the roll.



Applications:

The rewinder has a range of applications, from rotary die cutting, slitting machines to flexographic printing machines. Plus, it's designed with a 1-inch, 1.5-inch, and 2-inch quick release air-expansion shaft.

What's more, the rewinding machine is equipped with sophisticated automated production system. This feature allows for a seamless transition during reel size adjustments with no need for manual or mechanical adjustment. In this way, human labor force can be significantly reduced for an intelligent production.



Customization:

INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT

Brand Name: Supreme
Model Number: SZ
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Fumigation Wooden Box
Delivery Time: 50-60 Working Days
Payment Terms: TT;LC
Supply Ability: 30sets/Month
Applications: Full Rotary/Semi Intermittent Rotary/Mark Andy/Omit/Neil Peter Flexo Printing/Slitting Machinery
Advantage: 1 Inch, 1.5 Inch, 40mm, 3 Inch Auto Inflatable Air Shaft
Design: Self Devolopment And Patented
Size: 330/450/570mm
Service: OEM/ODM

Our INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT can help you material saving and reduce glue cost. We have No glue turret slitter machine price and 4 Dual Turret Slitter Rewinder for your choice. Our product is certified by CE and comes with fumigation wooden box. It takes 50-60 working days for delivery and you can make payment by TT or LC. We can provide OEM/ODM services and we have self devolopment and patented designs. The size of our product is 330/450/570mm.



Support and Services:

Technical Support and Services for INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT

We offer a full range of technical support and services for INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT, including:

  • On-site installation and training
  • Remote technical support and diagnostics
  • Technical troubleshooting and repair
  • Warranty service
  • Regular maintenance
  • Spare parts supply

Our experienced team of technicians is available 24/7 to answer any questions or provide support, ensuring that your INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT runs smoothly and efficiently.



Packing and Shipping:

Packaging and Shipping

INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT is packaged in a secure, sturdy box and shipped safely to clients. It is shipped directly to the customer's address in order to ensure that the product arrives in the best condition.

The box is designed to protect the machinery from damage during shipping. It also ensures that the machinery arrives in the same condition as it was when it left the factory.

The box also contains instructions on how to install and use the machinery, as well as safety precautions that must be followed when using the equipment.



FAQ:

Q: What is the brand name of INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT?
A: The brand name of INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT is Supreme.
Q: What is the model number of INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT?
A: The model number of INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT is SZ.
Q: Where is INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT originated from?
A: INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT is originated from China.
Q: What is the minimum order quantity for INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT?
A: The minimum order quantity for INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT is 1.
Q: What is the certification of INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT?
A: The certification of INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT is CE.


Standard with the machine:
1. rewinding machine: SZ-330/SZ-450/SZ-570: 1 piece
2. tube delivery rack: 1 piece

3. vibration plate:1 piece
4. Air shaft:SZ-330/SZ-450/SZ-570:12 pieces

5. Tool box: 1 box

6. internal hexagonal wrench:1 set

7: open spanner:10-17:1 group

8: Slotted screwdriver and cross screwdriver: 1piece/each

9: Level adjuster screw: 4 piece

10: circlip plier: 6#: 2 pieces

11:Oil gun: 1 piece

12:magnetic valve:DC24V:2 pieces

13:Relay:DC24V:2pieces

14:encoder:DBS36E-S3AK02000: Germany Sick: 1 piece

15:330/450/570 knife:1 pieces

16:Auto labeling device:1 set



Specification:

Machine Model SZ-330 SZ-450 SZ-570

Max rewinding diameter

(glue type)

350mm 350mm 350mm

Max rewinding diameter

(glue free)

200mm 200mm 200mm
Max Paper feeding 330mm 450mm 570mm
Max rewinding speed 50-120m/min 50-120m/min 50-120m/min
Mini rewinding width 30mm 30mm 30mm
Power source 380V/3P/50HZ 380V/3P/50HZ 380V/3P/50HZ
Power 13 kw 13 kw 13kw
Air source 0.8Mpa 1m3/min 0.8Mpa 1.5m3/min 0.8Mpa 1.5m3/min
Machine Dimensions

2020x2080x2800mm

(glue type)

3700 x2080 x2800

(glue free)

2020x2080x2800mm

(glue type)

3700 x2080 x2800

(glue free)

2020x2200x2800mm

(glue type)

3700 x2200 x2800

(glue free)

Machine weight

2500 kgs (glue type)

3500 kgs (glue free)

2500 kgs (glue type)

3500 kgs (glue free)

2800 kgs (glue type)

3800 kgs (glue free)



Automatic 4 spindles paper non stop label turret slitter rewinder save labor cost and improve efficiency



The advantage of ours machine(finished by glue-less non-stop turret rewinder):

1:No creases 2:Zero waste 3:save glue cost 4:save electricity consumptions PS others:1:Fold on the label 2:4-5 label waste at least



About us:

Professionally research and development in label flexographic printing machine, label die cutting machine, label slitting machine and Some other auxiliary equipment, We focus on talents and technological innovation, Adhere to the development strategy of "technical innovation, national brand", making the company a leader in the production line of label machinery.

Honesty, high quality, and service are our business tenet. Forge ahead, pragmatic and efficient are our corporate spirit. We research and manufacture various types of label machines, and welcome all new and old customers and friends to visit!





Because of upgraded and development, above datasheet just for reference, for the newest machinery, please enquiry our company. The finally interpretation is owned by our company

INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT 1INNOVATIVE ADHESIVE LABEL PAPER PROCESS MACHINERY SELF DEVOLOPMENT PATENTED NON-STOP REWINDING AUTOMATIC TURRET 4 SHAFT 2
