EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER

Basic Information
Place of Origin: China
Brand Name: Supreme
Certification: CE
Model Number: SZ
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: fumigation wooden box
Delivery Time: 50-60 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30sets/month
Detail Information
Product Name: EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER Color: Customized
Material: Paper Adhesive Sticker Label Layers Design: Self Devolopment And Patented
Voltage: 220V/380V Type: Lable Adhesive Paper Sticker Solution
Applications: Full Rotary/semi Intermittent Rotary/Mark Andy/Omit/Neil Peter Flexo Printing/slitting Machinery Video: For Video Sent Please Wechat/wa Me:+8618072118971
Language: Can Customized Into Client Regular Language For Easy Operations Note: Because Of Upgraded And Development, Above Datasheet Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company
Note: Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company

Product Description

EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER

Product Description:

The Automatic Turret 4 shafts rewinder is a fully automated rewinding machine, typically used in label production. This machine works together with slitting station or a multifunctional machine. It enables uninterrupted rewinding operations to better increase the production efficiency.

The machine can rewind printed or blank labels after slitting.

The following are its features:

  • Automatic core loading is supported by a storage tower for small cores.
  • Automatic feeding system working with a mechanical arm ensures precision positioning of cores onto the rewind shaft.
  • PLC and touch screen for user-friendly and convenient operation.
  • Automatic labeling sealing has been standardized and allows for more favorable pricing.
  • Automatic roll eject system saves time.
  • 4-spindle automatic turret rewinding.
  • No changeovers necessary (except for rewind shafts).
  • High speed: 50-120m/min.
  • Double-sided heavy machine body for stable operation at high speed.
  • Low maintenance due to a specialized turret.
  • High production efficiency with single expansion shaft for eight-die rewinding roll without crop loss.


Applications:

The rewinder is specially designed for connection to rotary die-cutting, slitting machines, flexographic printing machines and other machineries. It is equipped with 1-inch, 1.5-inch and 2-inch quick release air-expansion shafts, making it easier to handle reels of different sizes. This rewinding machine uses an automated system that allows it to easily adjust the size of the reels automatically without the need for manual or mechanical editing, reducing the labor force required and optimizing the production process.



Customization:

Customized EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER from Supreme

Supreme proudly presents its EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER, with the following features:

  • Brand Name: Supreme
  • Model Number: SZ
  • Place of Origin: China
  • Certification: CE
  • Minimum Order Quantity: 1
  • Price: Negotiation
  • Packaging Details: Fumigation Wooden Box
  • Delivery Time: 50-60 Working Days
  • Payment Terms: TT;LC
  • Supply Ability: 30sets/month
  • Material: Paper Adhesive Sticker Label Layers
  • Rewinding Part: AB Turret Graphic Rewinding
  • Voltage: 220V/380V
  • Applications: Full Rotary/semi Intermittent Rotary/Mark Andy/Omit/Neil Peter Flexo Printing/slitting Machinery
  • Type: Lable Adhesive Paper Sticker Solution

Our EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER is also ideal for label no glue turret slitter rewinder semi auto applications, making it the ideal agent wanted turret slitting machinery rewinder machine. And to answer the question “What is a turret rewinder?”, a turret rewinder is a machine that is used to roll up the label into a roll after it has been printed.



Support and Services:

Technical Support and Services for EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER

We offer comprehensive technical support and services to help you get the most out of your EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER. Our team of experienced engineers can provide you with the knowledge and expertise to ensure the highest levels of performance and reliability from your machinery.

We offer a wide range of services, including:

  • Installation and commissioning assistance
  • Regular maintenance and servicing
  • Repair and replacement of faulty parts
  • Troubleshooting and problem-solving advice
  • Technical advice and support
  • Training and operator instruction

We also offer online support to help you get the most out of your machinery. Our team is available 24/7 to answer any questions you may have and provide you with the assistance you need.



Packing and Shipping:

EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER Packaging and Shipping:

The EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER is securely packaged in wooden boxes to ensure safe transportation. . The box is then marked with shipping mark and the shipment is sent to its destination.



FAQ:

Q: What is the Brand Name of EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER?
A: The Brand Name is Supreme.
Q: What is the Model Number of EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER?
A: The Model Number is SZ.
Q: Where is the Place of Origin of EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER?
A: The Place of Origin is China.
Q: What is the Certification of EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER?
A: The Certification is CE.
Q: What is the Minimum Order Quantity of EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER?
A: The Minimum Order Quantity is 1.


Standard with the machine:
1. rewinding machine: SZ-330/SZ-450/SZ-570: 1 piece
2. tube delivery rack: 1 piece

3. vibration plate:1 piece
4. Air shaft:SZ-330/SZ-450/SZ-570:12 pieces

5. Tool box: 1 box

6. internal hexagonal wrench:1 set

7: open spanner:10-17:1 group

8: Slotted screwdriver and cross screwdriver: 1piece/each

9: Level adjuster screw: 4 piece

10: circlip plier: 6#: 2 pieces

11:Oil gun: 1 piece

12:magnetic valve:DC24V:2 pieces

13:Relay:DC24V:2pieces

14:encoder:DBS36E-S3AK02000: Germany Sick: 1 piece

15:330/450/570 knife:1 pieces

16:Auto labeling device:1 set



Specification:

Machine Model SZ-330 SZ-450 SZ-570

Max rewinding diameter

(glue type)

350mm 350mm 350mm

Max rewinding diameter

(glue free)

200mm 200mm 200mm
Max Paper feeding 330mm 450mm 570mm
Max rewinding speed 50-120m/min 50-120m/min 50-120m/min
Mini rewinding width 30mm 30mm 30mm
Power source 380V/3P/50HZ 380V/3P/50HZ 380V/3P/50HZ
Power 13 kw 13 kw 13kw
Air source 0.8Mpa 1m3/min 0.8Mpa 1.5m3/min 0.8Mpa 1.5m3/min
Machine Dimensions

2020x2080x2800mm

(glue type)

3700 x2080 x2800

(glue free)

2020x2080x2800mm

(glue type)

3700 x2080 x2800

(glue free)

2020x2200x2800mm

(glue type)

3700 x2200 x2800

(glue free)

Machine weight

2500 kgs (glue type)

3500 kgs (glue free)

2500 kgs (glue type)

3500 kgs (glue free)

2800 kgs (glue type)

3800 kgs (glue free)



Automatic 4 spindles paper non stop label turret slitter rewinder save labor cost and improve efficiency



The advantage of ours machine(finished by glue-less non-stop turret rewinder):

1:No creases 2:Zero waste 3:save glue cost 4:save electricity consumptions PS others:1:Fold on the label 2:4-5 label waste at least



About us:

Professionally research and development in label flexographic printing machine, label die cutting machine, label slitting machine and Some other auxiliary equipment, We focus on talents and technological innovation, Adhere to the development strategy of "technical innovation, national brand", making the company a leader in the production line of label machinery.

Honesty, high quality, and service are our business tenet. Forge ahead, pragmatic and efficient are our corporate spirit. We research and manufacture various types of label machines, and welcome all new and old customers and friends to visit!





Because of upgraded and development, above datasheet just for reference, for the newest machinery, please enquiry our company. The finally interpretation is owned by our company

EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER 1EFFICIENTLY SAVE LABOR 2-3 PERSON FROM COST - SEMI INTERMITTENT ROTARY ONLINE WITH AUTOMATIC TURRET 4 SHAFTS REWINDER 2
