Voltage: | 380V | Max Speed: | 24000time/h |
---|---|---|---|
Max Rewinding Diameter: | 800mm | Max Material Pulling Length: | 80m/min |
Max Material Feeding Width: | 350mm | Die Cutting Precision: | +-0.1mm |
MOQ: | 1 Set | Unwinding Max Diameter: | 800mm |
Video: | For Video Sent Please Wechat/wa Me:+8618072118971 | Language: | Can Customized Into Client Regular Language For Easy Operations |
Product Name: | MQ-350G ADHESIVE LABEL PAPER PROCESS MACHINERY MAX MATERIAL PULLING LENGTH 80M/MIN 1 YEAR WARRANTY DIE CUTTER MACHINERY | Note: | Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company |
http://www.youtube.com/@labelturretrewindingmachinery
We have conducted our own research on this machine. Its flat bed structure and computer servo system draws material, allowing it to complete all processes including feeding, die cutting, waste discharge and rewinding sheet cutting within one time.
This machine is the best choice to work with high-speed roll label printing machines, flexo printing machines, satellite printing machines, PS printing machines, and batch-type printing machines, for die-cutting adhesive labels and adhesive label products.
Custom-made MQ-350G ADHESIVE LABEL PAPER PROCESS MACHINERY MAX MATERIAL PULLING LENGTH 80M/MIN 1 YEAR WARRANTY DIE CUTTER MACHINERY
We offer supreme quality MQ-350G ADHESIVE LABEL PAPER PROCESS MACHINERY MAX MATERIAL PULLING LENGTH 80M/MIN 1 YEAR WARRANTY DIE CUTTER MACHINERY, with the brand name of Supreme. The model number is MQ-350G, and it is originating from China. It has CE certification, and you can order a minimum quantity of 1. The price is negotiable, and the packaging details are fumigation wooden box. The delivery time is within 30-60 working days. You can make payment through TT or LC, and we can supply a maximum of 20 sets per month. The warranty is one year. The die cutting precision is +-0.1mm, the unwinding maximum diameter is 800mm, the maximum speed is 24000 times/h, and the maximum material feeding width is 350mm.
This MQ-350G ADHESIVE LABEL PAPER PROCESS MACHINERY MAX MATERIAL PULLING LENGTH 80M/MIN 1 YEAR WARRANTY DIE CUTTER MACHINERY is ideal for industrial die cutting machine for sale, commercial digital die cutting machine, and flatbed die cutting machine for sale.
We provide technical support and service for our MQ-350G ADHESIVE LABEL PAPER PROCESS MACHINERY MAX MATERIAL PULLING LENGTH 80M/MIN 1 YEAR WARRANTY DIE CUTTER MACHINERY. Our service team is available 24 hours a day, seven days a week to provide the best solutions for any issue related to the machinery. We provide on-site service and repair of the machinery as well as remote support. Our technicians are certified and experienced in troubleshooting and repairing any issue with the machinery. We also provide routine maintenance and preventive maintenance services to ensure maximum efficiency of the machinery.
In addition, we provide instructional and educational materials, such as user manuals, training videos, and webinars, to help our customers understand and use the machinery. We also offer a variety of online resources, such as troubleshooting guides, FAQs, and product support forums to address any issue.
MQ-350G ADHESIVE LABEL PAPER PROCESS MACHINERY MAX MATERIAL PULLING LENGTH 80M/MIN 1 YEAR WARRANTY DIE CUTTER MACHINERY packaging and shipping process:
Feature:
1.Adopt PLC system, motion controller
2.24000 times/h , ensure run fast,high accuracy working stable.
3. Use wood die cutter,cheap and durable.
4. Use servo motor for main motor and material pulling,to keep accuracy.
5. Rewind and unwind is separate, it is suitable for film and label die cutting
6. With high speed sheet cutting ,sheet cutting by rotary, controlled by servo motor.
model | MQ-350G |
Max. Feeding width | 350mm |
No.1 cutting area | 350mm*350mm |
Max. speed | 24000time/h |
Max.length of meter | 80米/分钟(80m/min) |
Position accuracy | ±0.10mm |
Position unwinder dia | 800mm |
Max.rewinder dia | 800mm |
Size(L*W*H) | 3300*1400*1500 |
Voltage | 380v,3phase |
Total power | 11kw |
Weight | 2800kg |
