Max Material Feeding Width: | 350mm | Model: | MQ-350G |
---|---|---|---|
Max Rewinding Diameter: | 800mm | Die Cutting Size: | 350mm*350mm |
Warranty: | 1 Year | Voltage: | 380V |
MOQ: | 1 Set | Unwinding Max Diameter: | 800mm |
Video: | For Video Sent Please Wechat/wa Me:+8618072118971 | Language: | Can Customized Into Client Regular Language For Easy Operations |
Product Name: | MAX MATERIAL FEEDING WIDTH 350MM ADHESIVE LABEL PAPER PROCESS MACHINERY FOR VOLTAGE 380V HIGH SPEED DIE CUTTING MACHINE | Note: | Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company |
http://www.youtube.com/@labelturretrewindingmachinery
This machine which is researched by us, has a flat bed structure and employs a computer servo system pull material. It can complete all the processes - feeding, die cutting, wast discharge, and rewinding sheet cutting - in one time with the aid of computer.
The high speed die cutting machine is specifically designed for adhesive label products. It is an ideal choice to combine with various types of printing machines such as roll label printing machines, flexo printing machines, satellitic printing machines, PS printing machines, and batch-type printing machines.
It can maximize printed label accuracy and enable the printed labels to be die cut accurately, quickly and neatly.
The die cutting machine is equipped with a servo motor, allowing them to respond quickly and accurately to set the machine in motion, adjust speed and position accurately.
We provide technical support and service for our MAX MATERIAL FEEDING WIDTH 350MM ADHESIVE LABEL PAPER PROCESS MACHINERY FOR VOLTAGE 380V HIGH SPEED DIE CUTTING MACHINE products. Our experienced technicians are available to provide on-site service and support for installation, repair, maintenance, and troubleshooting issues. We are also available to answer any questions you may have about using the machinery and its features.
We offer a wide range of services, including:
We are committed to providing quality service and support for our MAX MATERIAL FEEDING WIDTH 350MM ADHESIVE LABEL PAPER PROCESS MACHINERY FOR VOLTAGE 380V HIGH SPEED DIE CUTTING MACHINE products. If you have any questions or need additional assistance, please contact us.
MAX MATERIAL FEEDING WIDTH 350MM ADHESIVE LABEL PAPER PROCESS MACHINERY FOR VOLTAGE 380V HIGH SPEED DIE CUTTING MACHINE Packaging and Shipping:
A1: The brand name of MAX MATERIAL FEEDING WIDTH 350MM ADHESIVE LABEL PAPER PROCESS MACHINERY FOR VOLTAGE 380V HIGH SPEED DIE CUTTING MACHINE is Supreme.
A2: Our MAX MATERIAL FEEDING WIDTH 350MM ADHESIVE LABEL PAPER PROCESS MACHINERY FOR VOLTAGE 380V HIGH SPEED DIE CUTTING MACHINE model number is MQ-350G.
A3: MAX MATERIAL FEEDING WIDTH 350MM ADHESIVE LABEL PAPER PROCESS MACHINERY FOR VOLTAGE 380V HIGH SPEED DIE CUTTING MACHINE is manufactured in China.
A4: Our MAX MATERIAL FEEDING WIDTH 350MM ADHESIVE LABEL PAPER PROCESS MACHINERY FOR VOLTAGE 380V HIGH SPEED DIE CUTTING MACHINE has CE certification.
A5: The minimum order quantity for MAX MATERIAL FEEDING WIDTH 350MM ADHESIVE LABEL PAPER PROCESS MACHINERY FOR VOLTAGE 380V HIGH SPEED DIE CUTTING MACHINE is 1.
Feature:
1.Adopt PLC system, motion controller
2.24000 times/h , ensure run fast,high accuracy working stable.
3. Use wood die cutter,cheap and durable.
4. Use servo motor for main motor and material pulling,to keep accuracy.
5. Rewind and unwind is separate, it is suitable for film and label die cutting
6. With high speed sheet cutting ,sheet cutting by rotary, controlled by servo motor.
model | MQ-350G |
Max. Feeding width | 350mm |
No.1 cutting area | 350mm*350mm |
Max. speed | 24000time/h |
Max.length of meter | 80米/分钟(80m/min) |
Position accuracy | ±0.10mm |
Position unwinder dia | 800mm |
Max.rewinder dia | 800mm |
Size(L*W*H) | 3300*1400*1500 |
Voltage | 380v,3phase |
Total power | 11kw |
Weight | 2800kg |
