320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT

Basic Information
Place of Origin: China
Brand Name: Supreme
Certification: CE
Model Number: MQ-350YII
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: fumigation wooden box
Delivery Time: 30-60 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 20sets/month
Detail Information
Die Cutting Length: 200mm-450mm (intermittent) 250mm-550mm (full Rotary) Power: 12kw
Warranty: 1 Year Slitting Speed: 120m/min
MOQ: 1 Set Max Material Feeding Width: 320mm
Model: MQ-350YII Max Rewinding Diameter: 650mm
Video: For Video Sent Please Wechat/wa Me:+8618072118971 Language: Can Customized Into Client Regular Language For Easy Operations
Product Name: 320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT Note: Because Of Upgraded And Development, Above Datasheet Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company
Note: Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company

Product Description

320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT

Product Description:

The MQ-350YII Semi-rotary Die Cutting with Slitting Machine is a brand new product equipped with motion control system and register sensor. This highly advanced machine offers precise rotary die-cutting capabilities and is specially designed for pre-printed labels.

Featuring an all-in-one process, the machine can easily complete unwinding, rotary die-cutting, slitting, and rewinding tasks. It can operate in both semi-rotary and full rotary modes, eliminating the need for changing magnetic cylinders when switching between different labels. Only the flexible die needs to be changed, making it a more time and cost-efficient option.

The machine comes equipped with a web guide to ensure smooth material handling. Its compact structure, fast speed, high efficiency, and accurate slitting make it a top choice for label production. Additionally, its user-friendly interface and steady running add to its many desirable features.



Applications:

This machine is suitable for pre-printed labels

The machine offers a one-step process for unwinding, rotary die-cutting, slitting, and rewinding. It can operate in both semi-rotary and full rotary modes. In semi-rotary mode, the machine has the ability to reverse, eliminating the need to change magnetic cylinders for different label sizes. Only a flexible die needs to be replaced.



Customization:

320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT Customization Service
Brand Name: Supreme
Model Number: MQ-350YII
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Fumigation wooden box
Delivery Time: 30-60 working days
Payment Terms: TT;LC
Supply Ability: 20 sets/month
Power: 12kw
Voltage: 380V
Die Cutting Length: 200mm-450mm (intermittent) 250mm-550mm (full Rotary)
Max Speed: 60m/min (intermittent) 120m/min (full-rotary)
Unwinding Max Diameter: 650mm

This 320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT is a customization service provided by Supreme. Our model number MQ-350YII is perfect for your label cutting needs. It is manufactured in China and has obtained the CE certification for its high quality and safety standards.

Our minimum order quantity is 1, and the price is available for negotiation. The packaging details include a fumigation wooden box to ensure the safety of the product during transportation. The delivery time is 30-60 working days, depending on the customization requirements.

We offer flexible payment terms including TT and LC for your convenience. With a supply ability of 20 sets per month, we can ensure a timely delivery for your orders.

The 320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT has a power of 12kw and operates on 380V voltage. The die cutting length can range from 200mm to 450mm for intermittent cutting, and 250mm to 550mm for full rotary cutting. With a maximum speed of 60m/min for intermittent cutting and 120m/min for full rotary cutting, our machinery can efficiently handle your label cutting needs.

The unwinding max diameter is 650mm, allowing for a large amount of paper to be processed at once. Our machinery is equipped with a semi rotary die cutter, which is a versatile and efficient cutting method. It also features the HD Quick Change Die Cut Semi Rotary Rotary Semi-Rotary Label Die Cutting Machine, which allows for quick and easy die changes for different label designs and sizes. This makes our machinery suitable for a wide range of label cutting and finishing needs.

Choose Supreme for your 320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT customization service and experience high-quality and efficient label cutting and finishing. Contact us now for more information and to place your order!

Support and Services:

320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT Technical Support and Service

At 320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT, we are committed to providing our customers with the highest quality technical support and service. Our team of experienced engineers and technicians are dedicated to ensuring that your machinery operates efficiently and effectively, minimizing downtime and maximizing productivity.

Technical Support

We offer comprehensive technical support services to assist you with any issues or questions you may have regarding your 320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT. Our technical support team is available 24/7 to provide you with prompt and reliable assistance. We offer support through phone, email, and online chat, and can also provide on-site support if needed.

Our technical support services include:

  • Troubleshooting and problem solving
  • Machine maintenance and repairs
  • Upgrades and modifications
  • Training and education
Service

In addition to technical support, we also offer comprehensive service options to keep your 320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT running smoothly. Our service technicians are highly trained and experienced, and can provide regular maintenance, repairs, and upgrades to ensure your machinery is always operating at its best.

Our service options include:

  • Preventative maintenance programs
  • On-site repairs and troubleshooting
  • Equipment upgrades and modifications
  • Replacement parts and components

With 320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT, you can trust that you will receive top-notch technical support and service to keep your machinery running at its best. Contact us today for more information or to schedule a service appointment.



Packing and Shipping:



Packaging and Shipping

The 320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT is packed and shipped in a sturdy wooden crate to ensure safe delivery to our customers..

The crate is then sealed with strong straps and labeled with the product name and shipping information for easy identification. We also include a detailed instruction manual and any necessary tools for assembly and installation.

For shipping, we use reliable and efficient transportation services to ensure timely delivery worldwide. We also provide insurance for the product during transit to give our customers added peace of mind.

Upon arrival, our customers can expect to receive their 320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT in excellent condition and ready for use. We strive to make the packaging and shipping process as smooth and hassle-free as possible for our valued customers.



FAQ:



.

2. Main Technical Parameters:



Slitting speed 120m/min
Die-cutting speed 60m/min (intermittent)
120m/min (full-rotary)
Max web width 320mm
Max unwinding diameter 650 mm
Max rewinding diameter 650 mm
Die cutting length 200mm-450mm (intermittent)
250mm-550mm (full rotary)
Overall diameter 2300* 1300* 1500mm
Machine weight 1000kgs
Voltage 380V, 3P
Power 12KW



3. Standard configuration:

  • One rotary die cutting station with waste rewinder shaft
  • One Lamination station with waste rewind for over-lamination film with liner
  • With 1pc 3’’ unwinding shaft with tension controller.
  • With 2pcs 3'' air shaft for rewind
  • With meter/number counter.
  • With one register sensor
  • With 8 pcs rotary knife.
  • Machine has blower fan to blow away the trimmed sides.
  • With auto web guiding

320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT 0320MM MAX MATERIAL FEEDING WIDTH - SEMI ROTARY LABEL AND SLITTING DIE CUTTING MACHINE OPTIONAL TURRET REWINDING 2 SHAFT 1
