HIGH SPEED LABEL SLITTING MACHINE WITH 0.8MPA AIR SUPPLY AND LONG-LASTING PERFORMANCE NARROW LABEL MEDIUM SPEED SLITTING

Basic Information
Place of Origin: China
Brand Name: Supreme
Certification: CE
Model Number: FQ-350FZ
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: fumigation wooden box
Delivery Time: 20-30 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 40sets/month
Detail Information
Mini Slit Width: 16mm Max Material Feeding Width: 350mm
Model: FQ-350FZ Max Rewinding Diameter: 600mm
Air Supply: 0.8mpa Unwinding Max Diameter: 600mm
Warranty: 1 Year Slitting Speed: 200m/min
Video: For Video Sent Please Wechat/wa Me:+8618072118971 Language: Can Customized Into Client Regular Language For Easy Operations
Product Name: HIGH SPEED LABEL SLITTING MACHINE WITH 0.8MPA AIR SUPPLY AND LONG-LASTING PERFORMANCE NARROW LABEL MEDIUM SPEED SLITTING Note: Because Of Upgraded And Development, Above Datasheet Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company
Note: Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company

Product Description

HIGH SPEED LABEL SLITTING MACHINE WITH 0.8MPA AIR SUPPLY AND LONG-LASTING PERFORMANCE NARROW LABEL MEDIUM SPEED SLITTING

Product Description:

This machine is a product independently researched and developed by our company. It is a narrow label medium speed slitting machine, a high-end, fully servo, unwinding and rewinding taper tension system, and equipped with imported famous brand web guide system.

It has a turret rewinding air shaft fully automatic rotation and transposition device, as well as a preparatory air shaft preparation device, which greatly improves production efficiency. It also supports the exchange of multiple specifications for inflatable shafts, along with meter/number counting, static treatment, no material to reduce speed or stop function, and cutting.



Applications:

This is a narrow label, medium speed slitting machine.

This versatile machine has many uses. It can be used for trimming the edges of labels or to rewind pressure-sensitive adhesive materials.

It is also suitable for the slitting operations of PET films, PVC films, paper and other packaging materials. With compact design and reliable performance, this machine can provide dependable slitting services.

Its features including an adjustable speed range, optional un-winding shaft, digital photoelectric automatic tracking and more. This machine offers enhanced accuracy, faster production and easy operation.



Customization:

HIGH SPEED LABEL SLITTING MACHINE WITH 0.8MPA AIR SUPPLY AND LONG-LASTING PERFORMANCE NARROW LABEL MEDIUM SPEED SLITTING

Brand Name: Supreme
Model Number: FQ-350FZ
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: fumigation wooden box
Delivery Time: 20-30 working days
Payment Terms: TT;LC
Supply Ability: 40sets/month
Slitting Speed: 200m/min
Max Rewinding Diameter: 600mm
Warranty: 1 Year
Air Supply: 0.8mpa
Max Material Feeding Width: 350mm

Supreme's FQ-350FZ HIGH SPEED LABEL SLITTING MACHINE WITH 0.8MPA AIR SUPPLY AND LONG-LASTING PERFORMANCE NARROW LABEL MEDIUM SPEED SLITTING is a high-speed label slitting machine with a rotary die-cutting station(optional). It is specially designed for narrow scope paper that requires a slitting speed of 200m/min and a maximum rewinding diameter of 600mm. It has a maximum material feeding width of 350mm and air supply of 0.8mpa. It comes with a 1-year warranty and is certified with CE. The minimum order quantity is 1 and the price is negotiable. It is packaged with a fumigation wooden box and the delivery time is 20-30 working days. Payment terms are TT;LC and the supply ability is 40sets/month.



Support and Services:

Technical Support and Service for HIGH SPEED LABEL SLITTING MACHINE WITH 0.8MPA AIR SUPPLY AND LONG-LASTING PERFORMANCE NARROW LABEL MEDIUM SPEED SLITTING

Our team strives to provide excellent technical support and service for HIGH SPEED LABEL SLITTING MACHINE WITH 0.8MPA AIR SUPPLY AND LONG-LASTING PERFORMANCE NARROW LABEL MEDIUM SPEED SLITTING. We offer:

  • 24/7 online support for any technical and operational enquiries
  • On-site maintenance and repair services
  • Regular safety inspections and quality control
  • Software updates and upgrades
  • Tailored preventive maintenance plans
  • Troubleshooting and troubleshooting assistance
  • Access to technical resources and documentation
  • Parts and components replacement


Packing and Shipping:

The HIGH SPEED LABEL SLITTING MACHINE WITH 0.8MPA AIR SUPPLY AND LONG-LASTING PERFORMANCE NARROW LABEL MEDIUM SPEED SLITTING product is packaged and shipped in accordance with its size and weight. Once it is ready for shipment, it is carefully wrapped in protective materials to ensure that it arrives in perfect condition. After the wrapping is complete, the product is placed in a sturdy wooden box with the appropriate a shipping label.

 The box is then ready to be picked up by the shipping company and sent to the customer's specified address. Tracking information and other details are provided to the customer to ensure that their product arrives safely and on time.



FAQ:

Q: What is the brand name of this product?
A: The brand name of this product is Supreme.
Q: What is the model number of this product?
A: The model number of this product is FQ-350FZ.
Q: Where is this product made?
A: This product is made in China.
Q: What certification does this product have?
A: This product has CE certification.
Q: What is the minimum order quantity of this product?
A: The minimum order quantity of this product is 1.


Feature:

1:Unwinding+web guide: adopts an independent servo taper tension control system, with preset automatic no material speed reduced or stop. web guide adopts ultrasonic edge guidance



2:Slitting station: Portable circular knife cutting structure, quick disassembly and assembly, optional flat knife, with high-pressure vacuum waste suction system



3:Rewinding: Taper tension control system, rotating device greatly saves roll changing time, ensuring label alignment with paper core during roll changing



4:Counting: The counting system adopts a well-known German brand, ensuring a calculation accuracy of 1/10000. Transparent materials require the purchase of additional special sensors



Technical Data

型号 model FQ-350FZ FQ-450FZ
最快分切速度 Max. Slitting speed 200m/min
最大进纸宽度 Max web width 350mm 450mm
最小分切宽度 Min. Slitting width 16mm
剪切刀具数量 Cutter installed 8sets
最大放卷直径 Max. Unwinding Dia 600mm
最大收卷直径 Max. Rewinding Dia 600mm
气压要求 Air supply 0.8mpa
重量 weight 500kg/600kg
外形尺寸 Dimension(L*W*H) 1100*1000*1200mm/1100*1100*1200mm



About us:

Professionally research and development in label flexographic printing machine, label die cutting machine, label slitting machine and Some other auxiliary equipment, We focus on talents and technological innovation, Adhere to the development strategy of "technical innovation, national brand", making the company a leader in the production line of label machinery.

Honesty, high quality, and service are our business tenet. Forge ahead, pragmatic and efficient are our corporate spirit. We research and manufacture various types of label machines, and welcome all new and old customers and friends to visit!





Because of upgraded and development, above datasheet just for reference, for the newest machinery, please enquiry our company. The finally interpretation is owned by our company
