Place of Origin: | China |
---|---|
Brand Name: | Supreme |
Certification: | CE |
Model Number: | FQ-350FZ |
Minimum Order Quantity: | 1 |
Price: | negotiation |
Packaging Details: | fumigation wooden box |
Delivery Time: | 20-30 working days |
Payment Terms: | L/C, T/T, Western Union, MoneyGram |
Supply Ability: | 40sets/month |
Model: | FQ-350FZ | Voltage: | 380V/220V |
---|---|---|---|
Air Supply: | 0.8mpa | Mini Slit Width: | 16mm |
Warranty: | 1 Year | Unwinding Max Diameter: | 600mm |
Slitting Speed: | 200m/min | Max Rewinding Diameter: | 600mm |
Video: | For Video Sent Please Wechat/wa Me:+8618072118971 | Language: | Can Customized Into Client Regular Language For Easy Operations |
Product Name: | FQ-350FZ SLITTING SPEED 200M/MIN ADHESIVE LABEL PAPER PROCESS MACHINERY 1 YEAR MEDIUM SPEED SLITTING MACHINE WITH TURRET | Note: | Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company |
Our company independently reseached and developed this machine, which is a high-end medium speed slitting machine.
It features with a fully servo unwinding and rewinding taper tension system and an imported famous brand web guide system.
The turret rewinding air shaft is fully automatic rotation and transposition device together with a preparatory air shaft preparation device, an outcome of great success.
This machine also supports the exchange of multiple specifications of inflatable shafts, meter/number counting, static treatment, no material to reduce speed or stop function, casing function, automatic deviation correction, brown paper splicing, and other functions.
This particular slitting machine is considered narrow label and is a medium speed type. It is typically used for cutting thin materials such as paper, film and foil. The machine is designed to make high quality linear cuts, depending on the thickness and type of the material. It has a user-friendly control panel and is easy to set up and operate. It is also equipped with automated safety features for safe and efficient production.
This slitting machine is widely used for many applications in various industries such as printing, packaging, clothing and textile industries. It is also suitable for a wide range of materials including PVC, PET, polyester, paperboard, corrugated paper, and aluminum and copper foils. It is also designed with different types of blades for different materials, ensuring that the cutting process is efficient, accurate and reliable.
This narrow label medium speed slitting machine is a reliable, high performance and cost-effective solution that can meet any slitting requirements you may have. It is also extremely easy to operate and maintain, making it a great choice for any production line.
Brand Name: Supreme
Model Number: FQ-350FZ
Place of Origin: China
Certification: CE
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: fumigation wooden box
Delivery Time: 20-30 working days
Payment Terms: TT;LC
Supply Ability: 40sets/month
Unwinding Max Diameter: 600mm
Warranty: 1 Year
Model: FQ-350FZ
Slitting Speed: 200m/min
Voltage: 380V/220V
Supreme's FQ-350FZ SLITTING SPEED 200M/MIN ADHESIVE LABEL PAPER PROCESS MACHINERY 1 YEAR MEDIUM SPEED SLITTING MACHINE WITH TURRET, model FQ-350FZ, is a best high speed label slitting machine with non stop rewinding machine(optional). It is certified with CE and comes with a 1 year warranty. The Unwinding Max Diameter is 600mm and the Slitting Speed is 200m/min. This machine runs on 380V/220V and is able to supply 40 sets/month. The minimum order quantity is 1 and the delivery time is 20-30 working days. The price is available for negotiation and the packaging is done with fumigation wooden box. Payment terms are TT;LC.
It is one of the different types of slitting machines, providing a variety of functions, including slitting, rewinding, and cutting. With its high precision and speed, this FQ-350FZ SLITTING SPEED 200M/MIN ADHESIVE LABEL PAPER PROCESS MACHINERY 1 YEAR MEDIUM SPEED SLITTING MACHINE WITH TURRET is ideal for label and paper processing.
We are proud to provide technical support and service for FQ-350FZ SLITTING SPEED 200M/MIN ADHESIVE LABEL PAPER PROCESS MACHINERY 1 YEAR MEDIUM SPEED SLITTING MACHINE WITH TURRET. We are available to assist with any technical questions or issues that may arise when using our products. Our team of experienced professionals is always ready to help you out.
We provide technical support in the following ways:
If you need any technical support or service for your FQ-350FZ SLITTING SPEED 200M/MIN ADHESIVE LABEL PAPER PROCESS MACHINERY 1 YEAR MEDIUM SPEED SLITTING MACHINE WITH TURRET, please contact us today.
FQ-350FZ SLITTING SPEED 200M/MIN ADHESIVE LABEL PAPER PROCESS MACHINERY 1 YEAR MEDIUM SPEED SLITTING MACHINE WITH TURRET is packaged for safe transport, using wooden crates and pallets to protect the machinery from damage. Specialized shock-absorbing materials may be used when needed. The packaging material used is certified to fulfill both international and national safety standards.
The machinery is shipped via air, sea, or land, depending on the customer’s preference and the distance to the destination. All shipments are tracked and monitored to ensure timely delivery.
Feature:
1:Unwinding+web guide: adopts an independent servo taper tension control system, with preset automatic no material speed reduced or stop. web guide adopts ultrasonic edge guidance
2:Slitting station: Portable circular knife cutting structure, quick disassembly and assembly, optional flat knife, with high-pressure vacuum waste suction system
3:Rewinding: Taper tension control system, rotating device greatly saves roll changing time, ensuring label alignment with paper core during roll changing
4:Counting: The counting system adopts a well-known German brand, ensuring a calculation accuracy of 1/10000. Transparent materials require the purchase of additional special sensors
Technical Data
型号 | model | FQ-350FZ | FQ-450FZ |
最快分切速度 | Max. Slitting speed | 200m/min | |
最大进纸宽度 | Max web width | 350mm | 450mm |
最小分切宽度 | Min. Slitting width | 16mm | |
剪切刀具数量 | Cutter installed | 8sets | |
最大放卷直径 | Max. Unwinding Dia | 600mm | |
最大收卷直径 | Max. Rewinding Dia | 600mm | |
气压要求 | Air supply | 0.8mpa | |
重量 | weight | 500kg/600kg | |
外形尺寸 | Dimension(L*W*H) | 1100*1000*1200mm/1100*1100*1200mm |
About us:
Professionally research and development in label flexographic printing machine, label die cutting machine, label slitting machine and Some other auxiliary equipment, We focus on talents and technological innovation, Adhere to the development strategy of "technical innovation, national brand", making the company a leader in the production line of label machinery.
Honesty, high quality, and service are our business tenet. Forge ahead, pragmatic and efficient are our corporate spirit. We research and manufacture various types of label machines, and welcome all new and old customers and friends to visit!
Because of upgraded and development, above datasheet just for reference, for the newest machinery, please enquiry our company. The finally interpretation is owned by our company
