FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER

Basic Information
Place of Origin: China
Brand Name: Supreme
Certification: CE
Model Number: FM-350
Minimum Order Quantity: 1
Price: negotiation
Packaging Details: fumigation wooden box
Delivery Time: 30-60 working days
Payment Terms: TT;LC, Western Union, MoneyGram
Supply Ability: 20sets/month
Detail Information
Suit For Paper Thickness: 105-500gsm Total Power: 16.5kw
Max Paper Diameter: 600mm Machine Weight: 450kg
Max Laminating Speed: 65m/min Warranty: 1 Year
Machine Size: 1655*1030*1235mm Model: FM-350
Video: For Video Sent Please Wechat/wa Me:+8618072118971 Language: Can Customized Into Client Regular Language For Easy Operations
Product Name: FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER Note: Because Of Upgraded And Development, Above Datasheet Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company
Note: Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company

Product Description

FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER

Product Description:

The machine has a compact structure, greatly saving land space for enterprises. It adopts oil pressure constant temperature heating control to ensure the quality of printed products. It adopts pre coating film, which is lower in cost than ordinary cold film. The machine adopts magnetic powder tension control for unwinding and rewinding to ensure machine quality.

Equipped with an automatic web guide, uneven products can also be perfectly coated, saving materials. This machine is a necessary post press helper for major printing enterprises and professional printing plants.



Applications:

This machine can provide great assistance to major printing enterprises. It is a essential post press helper in the printing industry.

It is widely used in professional printing shops and some large printing organizations. With the development of printing technology, post press machines help printing enterprises to improve printing quality and efficiency.

The machine is both reliable and well-designed. It is applied to various printing processes, and can greatly reduce production time and cost. Therefore, it is important for printing enterprises to have sufficient capacity to complete printing tasks.



Customization:

Supreme offers the High Speed industrial automatic laminating machine BOPP, Paper And Film Laminating Machine FM-350 with CE certification. The minimum order quantity is 1, and the price is negotiable. It comes in a fumigation wooden box. The delivery time is 30-60 working days, and the payment terms are TT or LC. The supply ability is 20sets/month. The FM-350 has a maximum laminating speed of 65m/min, a total power of 16.5kw, and is suitable for paper thicknesses of 105-500gsm. It comes with a 1 year warranty. If you are wondering How do you laminate laminating film?, the FM-350 is the perfect choice for you.



Support and Services:

FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER offers a comprehensive range of technical support and services, including:

  • Installation and commissioning assistance
  • On-site and remote technical support
  • Full training and user manuals
  • Maintenance and repair services
  • Spare parts and consumables supply
  • Software updates and upgrades


Packing and Shipping:

Packaging and Shipping

FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER’s packaging and shipping process begins with the selection of appropriate materials to protect and secure the product during transit. The boxes are then labeled according to the customer's address and the contents. The boxes are then loaded onto pallets and secured with shrink-wrap before being loaded onto the shipping truck.

The shipping truck is then loaded with the pallets and driven to the necessary destination. During transit, the truck is monitored to ensure the safe delivery of the product. Upon arrival at the destination, the product is unloaded and the customer is notified that the shipment has been received.



FAQ:

  • Q: What is the Brand Name of FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER?
    A: The Brand Name is Supreme.
  • Q: What is the Model Number of FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER?
    A: The Model Number is FM-350.
  • Q: Where is the Place of Origin of FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER?
    A: The Place of Origin of FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER is China.
  • Q: What is the Certification of FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER?
    A: The Certification of FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER is CE.
  • Q: What is the Minimum Order Quantity of FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER?
    A: The Minimum Order Quantity of FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER is 1.





Specifications:

model FM-350
Max paper diameter 600mm
Suit for paper thickness 105-500gsm
Max laminating speed 65m/min
Total power 16.5kw
Machine weight 450kg
Machine size 1655*1030*1235mm



1:The Orange-red baffle in the image is used to limit the position of the web paper, so as to avoid beyond the scope of correction

during processing.

roll to roll pre coating film Laminating machine oil pressure constant temperature heating electromagnetic heating

2:The yellow part in the image shows the manual oil pump, and above the oil pump is an oil pressure gauge for easy operation and monitoring of oil pressure at any time. The black valve body is locked to prevent oil pump pressure drop. The blue valve body at the bottom serves as a pressure regulating function, allowing for specified pressure and making it easier to achieve the required pressure by adjusting it

roll to roll pre coating film Laminating machine oil pressure constant temperature heating electromagnetic heating

3:Image 1 shows the overall deviation correction device. image 2 shows a U-shaped opposing sensor, which has high accuracy in correcting deviation and can accurately correct deviation regardless of the transparency of the material

roll to roll pre coating film Laminating machine oil pressure constant temperature heating electromagnetic heating

4:When one roll is finished and the next roll is replaced. Having this device can avoid frequent machine adjustments, paper threading, and positioning. Reduce machine stopping time

roll to roll pre coating film Laminating machine oil pressure constant temperature heating electromagnetic heating

5:216mm large diameter heating roller. The surface of the roller is polished with a mirror, providing a better texture, durability, and wear resistance. Stable heating.

roll to roll pre coating film Laminating machine oil pressure constant temperature heating electromagnetic heating

6:Commonly used for pre coating films with poor quality, wrinkles, unevenness, and uneven left and right sides. The left and right eccentric blocks can be adjusted appropriately. Maintain consistent tension between the left and right sides of the film to avoid wrinkling before entering the heating roller and affecting the quality of the film coating

roll to roll pre coating film Laminating machine oil pressure constant temperature heating electromagnetic heating

7:This machine adopts three tile type expansion shafts and abandons the fixed mode of air expansion shaft, completely freeing the machine from the constraints of the air compressor. Tile type expansion shaft is more convenient and fast

roll to roll pre coating film Laminating machine oil pressure constant temperature heating electromagnetic heating

8:Effectively control the tension of the film release shaft to prevent wrinkling caused by relaxation of the pre coated film, which affects the processing effect.

roll to roll pre coating film Laminating machine oil pressure constant temperature heating electromagnetic heating

9:paper drawing:

roll to roll pre coating film Laminating machine oil pressure constant temperature heating electromagnetic heating

FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER 9FM-350 ADHESIVE LABEL PAPER PROCESS MACHINERY BOOST EFFICIENCY WITH 65M/MIN LAMINATING PRE COATED POST PRESS HELPER 10
