Temperature Controller: | China | Model: | HBRY-W |
---|---|---|---|
Precision Of Registration: | +-0.1mm | Standard With Machine: | All The Rollers Are Deal With High Temperature. |
Machine Thickness: | 25mm | Max Roll Paper Width: | 350mm/450mm Or Customized |
Optional: | Servo Motor Driven | Video: | For Video Sent Please Wechat/wa Me:+8618072118971 |
Language: | Can Customized Into Client Regular Language For Easy Operations | Product Name: | BEST QUALITY CUSTOMIZABLE PROFESSIONAL INLINE FLEXO LABEL PRESS MANUFACTURER IN CHINA TEMPERATURE CONTROLLER OMRON |
Note: | Because Of Upgraded And Development, Machine Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company |
http://www.youtube.com/@labelturretrewindingmachinery
This machine is mainly used for 30-300g/m2 web printing, with a wide range of applicable products, ranging from trademarks, self-adhesive labels, computer forms, bills, aluminum foil, film, milk cardboard, battery film and carton pre-printing.
The printer features a flexible functional configuration and can be connected to additional devices to provide double-sided printing, self-adhesive peeling printing, UV varnishing, embossing, die cutting, Laminating, cold stamping, slitting and other processes.
This makes it a great choice for a range of specialised fields such as wine, cigarettes, medicine, cosmetics, milk packs, juice packs, and carton packaging (trademarks, boxes, bags, boxes, etc.)
This machine is mainly used for web printing ranging from 30 to 300g/m2. Different types of products are able to be printed through this machine, such as trademarks, self-adhesive labels, computer forms, bills, aluminum foil, film, battery film, milk cardboard, and pre-printed cartons.
Our company provides a wide range of technical support and service for BEST QUALITY CUSTOMIZABLE PROFESSIONAL INLINE FLEXO LABEL PRESS MANUFACTURER IN CHINA TEMPERATURE CONTROLLER OMRON, including:
We have experienced technicians and engineers available to provide comprehensive and professional technical support and service for all our customers.
BEST QUALITY CUSTOMIZABLE PROFESSIONAL INLINE FLEXO LABEL PRESS MANUFACTURER IN CHINA TEMPERATURE CONTROLLER OMRON is typically packaged in protective plastic film wrapped and placed in a sealed wooden crate. This ensures that it is protected during transit and arrives in the same condition it was shipped in. All machinery is shipped via a reputable carrier such as DHL, FedEx, or UPS.
Technical data | |
Model | HBRY-8350W |
Max unwinding diameter | 600mm |
Repeat printing length | 57T-158T |
Max paper width | 350mm |
Max printing width | 340mm |
Machine body thickness | 25mm |
Suit for material | 30-300gsm paper;alu foil:38-100micron |
Tension control range | 5-100kg |
Tension control accurate | +-1kg |
Gear | 1/8CP,teeth space 3.175mm |
Print plate thickness | 1.14mm |
Printing precision | +-0.1mm |
Double side tape thickness | 0.38mm |
Print servo motor power | 1.3KW+1.8KW |
Unwinding and rewinding also traction servo motor power | 2.9KW |
Machine max speed | 150m/min |
Air pressure | 0.8mpa |
Power requirement | 380V/3P/50HZ AC |
Total power | About 100KW without UV |
