Highly precise Fully automatic non-stop 4 spindle shaft turret rewinder for label slitting machinery

Basic Information
Place of Origin: China
Brand Name: Supreme
Certification: CE
Model Number: SZ-330B
Minimum Order Quantity: 1
Price: negotitaon
Packaging Details: fumigation wooden box
Delivery Time: 60 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 30set/mont
Detail Information
Label: Paper Adhesive Sticker Language: Can Customized Into Client Regular Language For Easy Operations
Application: Slitting And Rewinding Voltage: 220V/380V
Video: For Video Sent Please Wechat/wa Me:+8618072118971 Weight: 1000kg
Speed: 150m/min Size: 330/450/570mm
Note: Because Of Upgraded And Development, Above Datasheet And Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company

Product Description

Highly precise Fully automatic non-stop 4 spindle shaft turret rewinder for label slitting machinery

http://www.youtube.com/@labelturretrewindingmachinery

Product Description:

SZ-330/450/570B Label Automatic non-stop turret rewinding machine

Automatic non-stop turret rewinding machine is ideal intelligent narrow web label sticker automatic production converting equipment.


SZ series turret rewinder is with matured and most advanced technology in the world, and own the ability to work in-line with die cutting machine, printing machine, slitting machine and work off line as a stand-alone solution with a separate unwinder. Automatic tube threading, automatic gluing, automatic cutting & rewinding and automatic label sticking, which can finish your customers’ orders quickly, shorten the lead-time, increase your productivity, save your labor cost and raise your product competitive advantage in the market. It can accept both printed labels and blank labels rewinding.

Machine Specifications

This advanced machine has a top speed of 150 meters per minute. It is equipped with a powerful servo motor for precise control and offers a variety of impressive functions. These include slitting, automatic paper core loading (optional), automatic cutting, labeling, and rewinding. The paper core does not require any glue and will remain perfectly straight throughout the process. In addition, the machine boasts a meter counter, quantity counter, and the convenient option for automatic unloading.

Applications:

This type machine is our latest innovation for small label rolls automatic cutting and rewinding with high-efficiency.



Adhesive paper sticker labels can be created through various methods, including vertical and horizontal flexographic printing machinery. This allows for precision and consistency in the production process.

In addition to flexographic printing, intermittent semi and fully rotary die cutting machinery, as well as flatbed die cutting machinery, can be utilized for manufacturing these labels. These cutting methods can accommodate different label sizes and shapes.

For efficient production, high speed slitting machinery is also available for creating adhesive sticker labels on paper. This ensures that the labels are neatly cut and ready for use.It's suitable for blank lable,adhesive paper etc



1.Glusless - eco friendly environmental protections,also can save both glue and electricity cost
2.Automatic tail sticking-Label Tail Closure
3.Automatic paper core loading
4.Automatic roll eject(gluing type turret rewinding machine for labels)
5.Servo driven and with accurate loop consent tension control
6.Precisionly cut in gap between labels just right



Advantages: 1: increasing about 20% capacity than others brand machine 2:increasing the finished products quality 3:reduce the finished material waste 4: with competitive prices 5:no creases 6:zero waste 7:save glue cost 8: saving electricity consumptions

Customization:

Brand Name: Supreme
Model Number: SZ-330B
Place of Origin: Wenzhou
Certification: CE
Minimum Order Quantity: 1
Price: negotitaon
Packaging Details: fumigation wooden box
Delivery Time: 60 working days
Payment Terms: TT
Supply Ability: 30set/mont
Voltage: 220V/380V
Weight: 1000kg
Dimension: 1500*1200*3000mm
Applications: Online With High Speed Slitting And Rewinding Machinery For Adhesive Paper Sticker Labels
Color: White
Key Features:
  • Automatic NonStop Double Turret Slitter Rewinder
  • Full Automatic Non-Stop Turret Rewinder With Four Spindles For Label Rewinding
  • Label Sticker Narrow Web Fully Automatic Non-Stop Turret Rewinder Machine

4. Highly precise Fully automatic non-stop 4 spindle shaft turret rewinder for label slitting machinery

Support and Services:

  • 24/7 technical support via phone, email, and online chat
  • On-site installation and training by experienced technicians
  • Regular maintenance and inspection to ensure optimal performance(domestic clients)
  • Quick response time for any technical issues or inquiries
  • Remote troubleshooting and programming assistance
  • Upgrades and customization options available to meet specific production needs
  • Comprehensive user manual and training materials provided
  • In-house spare parts inventory for fast replacement and minimal downtime
  • Extended warranty options for additional peace of mind

Packing and Shipping:

.

FAQ:

  • Brand Name: Supreme

Q: What is the model number of this product? A: The model number is SZ-330B.

  • Model Number: SZ-330B

Q: Where is this product manufactured? A: This product is manufactured in Wenzhou.

  • Place of Origin: Wenzhou

Q: Does this product have any certifications? A: Yes, it is CE certified.

  • Certification: CE

Q: What is the minimum order quantity for this product? A: The minimum order quantity is 1.

  • Minimum Order Quantity: 1

Q: Is the price negotiable? A: Yes, the price is negotiable.

  • Price: negotitaon

Q: How is this product packaged? A: It is packaged in a fumigation wooden box.

  • Packaging Details: fumigation wooden box

Q: What is the delivery time for this product? A: The delivery time is 60 working days.

  • Delivery Time: 60 working days

Q: What are the payment terms for this product? A: The payment terms are TT.

  • Payment Terms: TT

Q: What is the supply ability for this product? A: The supply ability is 30 sets per month.

  • Supply Ability: 30 sets per month



Specification:

Machine Model SZ-330B SZ-450B
Max paper feeding 330mm 450mm
Max speed 150m/min 150m/min
Slitting precision +-0.1mm +-0.1mm
Max unwinding diameter 700mm(customized into 1000mm) 700mm
Max rewinding diameter 180mm(customized into 254mm) 180mm
Voltage 220V 1P 50HZ/380V 3P 50HZ 220V 1P 50HZ/380V 3P 50HZ
Total power 6KW 8KW
Machine weight

1000kg



1500kg



Machine size 1500*1200*3000mm 1500*1400*3100



Machine details:

1:slitting speed:150m/min

2:slitting precision:+-0.1mm

3:paper feeding width max:330mm

4:max unwinding diameter:700mm(customized into 1000mm)

5:max rewinding diameter:180mm(customized into 254mm)

6:machine weight:1000kg

7:machine voltage:220V/380V

8:Total power:6kw

9:machine size:1500*1200*3000mm

Unwinding part:

1:unwinding at air shaft: 3inch 1 piece

2:auto tension controller

3:auto web guide

Slitting part:

1:up knife:8 piece

2:down knife:8 piece

3:left and right hand wheel for adjustment

4:number counting photo-eyes

5:vacuum waste absorb

6:material pulling traction roller(servo)

Rewinding part:

1:auto turret rewinding system(servo)

2:rewinding air shaft(1 inch or 1.5inch at 2pieces)

3:auto inflation

4:no glue system

5:auto cutting system

6:auto labeling system

7:auto paper core feeding system(optional)

8:auto unloading(optional)



Highly precise Fully automatic non-stop 4 spindle shaft turret rewinder for label slitting machinery 0Highly precise Fully automatic non-stop 4 spindle shaft turret rewinder for label slitting machinery 1
