| Place of Origin: | China |
|---|---|
| Brand Name: | Supreme |
| Certification: | CE |
| Model Number: | SZ-330B |
| Minimum Order Quantity: | 1 |
| Price: | negotitaon |
| Packaging Details: | fumigation wooden box |
| Delivery Time: | 60 working days |
| Payment Terms: | L/C, T/T, MoneyGram, Western Union |
| Supply Ability: | 30set/mont |
| Size: | 330/450/570mm | Application: | Slitting And Rewinding |
|---|---|---|---|
| Power: | 6KW | Weight: | 1000kg |
| Speed: | 150m/min | Language: | Can Customized Into Client Regular Language For Easy Operations |
| Dimension: | 1500*1200*3000mm | Label: | Paper Adhesive Sticker |
| Video: | For Video Sent Please Wechat/wa Me:+8618072118971 | Note: | Because Of Upgraded And Development, Above Datasheet And Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company |
150m/min Fully automatic non-stop 4 spindle turret rewinder for label High-performance
http://www.youtube.com/@labelturretrewindingmachinery
This particular machine has a maximum operating speed of 150 meters per minute. It is efficiently operated by a powerful servo motor and boasts a variety of advanced capabilities including slitting, automatic paper core loading (optional), cutting, labeling, and rewinding.
The unique design of this machine allows for the paper core to remain strong and intact without the use of any additional adhesive, eliminating the potential for unwanted folding or creasing during the rewinding process. Additionally, this machine comes equipped with a reliable meter counter and quantity counter, as well as the option for automatic unloading for even greater efficiency.
The adhesive paper sticker labels can be produced online using vertical and horizontal flexographic printing machinery. Additionally, intermittent semi and fully rotary die cutting machinery and flatbed die cutting machinery can be used for manufacturing these labels. High speed slitting machinery is also available for producing adhesive sticker labels on paper.
Brand Name: Supreme
Model Number: SZ-330B
Place of Origin: Wenzhou
Certification: CE
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Fumigation Wooden Box
Delivery Time: 60 Working Days
Payment Terms: TT
Supply Ability: 30 Sets/Month
Applications: Online With High Speed Slitting And Rewinding Machinery For Adhesive Paper Sticker Labels
Adhesive Type: Sticker
Size: 330/450/570mm
Warranty: 1 Year
Type: Turret Slitting Rewinding Machine
Key Features: Label Sticker, Narrow Web, Fully Automatic, Non-Stop, Turret Rewinder Machine, Glueless, Adhesive Labels, Blank Labels, Latest Innovation
Our 150m/min Fully automatic non-stop 4 spindle turret rewinder for label High-performance is designed and manufactured with the latest technology and precision engineering to provide efficient and high-quality label slitting and rewinding solutions. As a leading provider of label converting machinery, we are committed to providing comprehensive technical support and services to ensure the smooth operation and maintenance of our machinery.
Our technical support and services include:
At Supreme, we are dedicated to providing top-notch technical support and services to ensure your satisfaction with our machinery. Contact us today to learn more about our products and services.
Our 150m/min Fully automatic non-stop 4 spindle turret rewinder for label High-performance is carefully packaged and shipped to ensure its safe arrival at your designated location. The packaging process includes:
We also offer customized packaging options to meet your specific needs.
For shipping, we work with trusted and reliable carriers to ensure timely and efficient delivery. Our shipping options include:
Once your order is shipped, we will provide you with a tracking number so you can monitor the status of your shipment.
Thank you for choosing our 150m/min Fully automatic non-stop 4 spindle turret rewinder for label High-performance. We are committed to ensuring its safe and timely delivery to you.
Specification:
| Machine Model | SZ-330B | SZ-450B |
| Max paper feeding | 330mm | 450mm |
| Max speed | 150m/min | 150m/min |
| Slitting precision | +-0.1mm | +-0.1mm |
| Max unwinding diameter | 700mm(customized into 1000mm) | 700mm |
| Max rewinding diameter | 180mm(customized into 254mm) | 180mm |
| Voltage | 220V 1P 50HZ/380V 3P 50HZ | 220V 1P 50HZ/380V 3P 50HZ |
| Total power | 6KW | 8KW |
| Machine weight |
1000kg
|
1500kg
|
| Machine size | 1500*1200*3000mm | 1500*1400*3100 |
Machine details:
1:slitting speed:150m/min
2:slitting precision:+-0.1mm
3:paper feeding width max:330mm
4:max unwinding diameter:700mm(customized into 1000mm)
5:max rewinding diameter:180mm(customized into 254mm)
6:machine weight:1000kg
7:machine voltage:220V/380V
8:Total power:6kw
9:machine size:1500*1200*3000mm
Unwinding part:
1:unwinding at air shaft: 3inch 1 piece
2:auto tension controller
3:auto web guide
Slitting part:
1:up knife:8 piece
2:down knife:8 piece
3:left and right hand wheel for adjustment
4:number counting photo-eyes
5:vacuum waste absorb
6:material pulling traction roller(servo)
Rewinding part:
1:auto turret rewinding system(servo)
2:rewinding air shaft(1 inch or 1.5inch at 2pieces)
3:auto inflation
4:no glue system
5:auto cutting system
6:auto labeling system
7:auto paper core feeding system(optional)
8:auto unloading(optional)
