| Place of Origin: | China |
|---|---|
| Brand Name: | Supreme |
| Certification: | CE |
| Model Number: | MQ-YIIE |
| Minimum Order Quantity: | 1 |
| Price: | Negotiation |
| Packaging Details: | Fumigation wooden box |
| Delivery Time: | 30-60 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 20sets/month |
| Type: | Intermittent | Power Consumption: | 15KW |
|---|---|---|---|
| Max Web Width: | 350mm | Die Cutting Type: | Semi-rotary |
| Application: | Label Adhesive Paper | Material: | Paper |
| Dimensions: | 2200* 1300* 1500mm | Max. Cutting Speed: | 50m/min (intermittent) |
| Video: | For Video Sent Please Wechat/wa Me:+8618072118971 | Language: | Can Customized Into Client Regular Language For Easy Operations |
| Note: | Because Of Upgraded And Development, Above Datasheet And Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company |
INTERMITTENT SEMI ROTARY LABEL DIE CUTTING WITH TURRET SLITTING AND REWINDING MACHINE SNOWBALL WASTE REWIND ECONOMICAL
http://www.youtube.com/@labelturretrewindingmachinery
Intermittent semi rotary die-cutting is a cutting-edge method of machining that utilizes a servo motor motion control system and color register sensors to ensure high precision in rotary die-cutting systems. This new processing concept, unique to this machine, eliminates the need for multiple magnetic cylinders, significantly reducing both time and costs associated with making cutting tools. It is particularly well-suited for pre printing labels as it can complete unwinding, rotary die-cutting, slitting, and rewinding in a single process. This versatile machine can operate in both semi rotary and full rotary mode, and boasts a compact structure, high speed, efficient performance, user-friendly operation, precise cutting, and smooth operation.
This device is appropriate for pre-printing labels.
Brand Name: Supreme
Model Number: MQ-YIIE
Place of Origin: Wenzhou
Certification: CE
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Fumigation wooden box
Delivery Time: 30-60 working days
Payment Terms: TT
Supply Ability: 20sets/month
Application: Label Adhesive Paper
Color: Customizable(standard Grey White)
Max web width: 350mm
Die Cutting Type: Semi-rotary
Material: Paper
Key Words: Die Cut Sticker Labels, Blank Label Die Cutting Machine, Fully Automatic Paper Cutting Machine
The INTERMITTENT SEMI ROTARY LABEL DIE CUTTING WITH TURRET SLITTING AND REWINDING MACHINE SNOWBALL WASTE REWIND ECONOMICAL is carefully packaged to ensure safe delivery to the customer. The machine is first wrapped in protective materials to prevent any damage during transit. It is then placed in a sturdy wooden box and secured with straps to prevent any movement during transportation.
For shipping, we use reliable and efficient courier services to ensure timely delivery. The package is labeled with clear instructions and handling precautions for the courier to follow.
Upon arrival, the customer can expect the package to be in excellent condition and ready for installation. Our team also provides assistance with unpacking and setting up the machine if needed. We take great care in packaging and shipping our products to ensure complete customer satisfaction.
2. Main Technical Parameters:
| Slitting speed | 120m/min |
| Die-cutting speed | 50m/min (intermittent) |
| 120m/min (full-rotary) | |
| Max web width | 350mm |
| Max unwinding diameter | 600 mm |
| Max rewinding diameter | 600 mm |
| Die cutting length | 480mm (intermittent) |
| 570mm (full rotary) | |
| Machine size | 2200* 1300* 1500mm |
| Machine weight | 1600kgs |
| Voltage | 380V, 3P |
| Power | 15KW |
| Standard magnetic cylinder | 150T(480mm) |
| Slitting width | 12-350mm |
| Die cutting precision | +-0.15mm |
