Inline Unit Petal Type Horizontal Flexographic Print Machinery Narrow Web Label Servo Driven LED UV Cold Stamp Mercury

Basic Information
Place of Origin: China
Brand Name: Supreme
Certification: CE
Model Number: RYW-350/450
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Fumigation wooden box
Delivery Time: 80-120 working days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 5set/mont
Detail Information
Adhesive Type: Paper Sticker Printing Type: Flexographic Printing
Color: Customized(standard Grey White) Label Type: Adhesive
Size: 350/450mm Video: For Video Sent Please Wechat/wa Me:+8618072118971
Language: Can Customized Into Client Regular Language For Easy Operations Note: Because Of Upgraded And Development, Above Datasheet And Image Just For Reference, For The Newest Machinery, Please Enquiry Our Company. The Finally Interpretation Is Owned By Our Company

Product Description

Inline Unit Petal Type Horizontal Flexographic Print Machinery Narrow Web Label Servo Driven LED UV Cold Stamp Mercury

http://www.youtube.com/@labelturretrewindingmachinery

Product Description:

.This machine is mainly used for 30-300g/m2 web printing. The types of products that can be printed include trademarks, self-adhesive labels, computer forms, bills, aluminum foil, film, milk cardboard, battery film, carton pre-printing, etc. The printer has flexible functional configuration and can be connected to realize double-sided printing(turn bar), self-adhesive peeling printing(relam and delam), UV varnishing(UV LED or Mercury), embossing, die cutting(full rotary),Film Laminating, cold foil stamping, slitting and other processes. It is ideal printing equipment for wine, cigarettes, medicine, cosmetics, milk packs, juice packs, carton packaging (trademarks, boxes, bags, boxes, etc.)

Applications:

This printer is primarily utilized for printing on web materials ranging from 30 to 300g/m2. It is capable of printing various products such as trademarks, self-adhesive labels, computer forms, bills, aluminum foil, film, milk cardboard, battery film, and pre-printed cartons.

It is the perfect printing equipment for industries such as wine, cigarettes, medicine, cosmetics, milk packaging, juice packaging, and carton packaging (including trademarks, boxes, bags, and more).



1:Cold foil is a printing technique that adds metallic and reflective effects to labels and packaging

2:Integrating a sheeter unit into a flexographic press significantly streamlines the printing process, making it more efficient and reducing material waste

3:The "delam relam" unit in flexographic printing is a component that carries out the process of delamination and relamination. Delamination is the process of separating two layers of material, while relamination is the process of reattaching the two layers together

4:A turn bar unit in flexography is a component used to change the web direction of a continuous substrate or web material as it moves through the printing press

5:A rotary die-cutting unit in flexographic printing is a key component that performs precise cuts and die-cutting into desired shapes in the printed material

Customization:

Supreme Inline Unit Petal Type Horizontal Flexographic Print Machinery Narrow Web Label Servo Driven LED UV Cold Stamp Mercury
Brand Name: Supreme
Model Number: RYW-350/450
Place of Origin: Wenzhou
Certification: CE
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Fumigation wooden box
Delivery Time: 80-120 working days
Payment Terms: TT
Supply Ability: 5set/month
Adhesive Type: Paper Sticker
Printing Method: Flexographic Printing
Printing Type: Flexographic Printing
Color: Customized (standard Grey White)
Sticker Type: Label

Our Inline Unit Petal Type Horizontal Flexographic Print Machinery Narrow Web Label Servo Driven LED UV Cold Stamp Mercury, Supreme RYW-350/450, is customized to meet your specific needs.

Featuring the latest technology and high-quality materials, our product is designed and manufactured in Wenzhou with CE certification.

With a minimum order quantity of 1 and negotiable pricing, we offer flexible options to meet your budget and requirements.

Our packaging is carefully chosen to ensure the safe delivery of our product - fumigation wooden boxes for added protection.

With a delivery time of 80-120 working days, we guarantee efficient and timely delivery of your order.

Payment terms are flexible, with TT as the preferred method.

Our supply ability is 5 sets per month, ensuring a steady and reliable supply of our product.

Choose from a variety of colors, or customize with your desired color - our standard is Grey White.

Delamination is the process of separating two layers of material, while relamination is the process of reattaching the two layers together.

Experience high-quality and efficient printing with our Inline Unit Petal Type Horizontal Flexographic Print Machinery Narrow Web Label Servo Driven LED UV Cold Stamp Mercury

Packing and Shipping:

Product Name: Inline Unit Petal Type Horizontal Flexographic Print Machinery Narrow Web Label Servo Driven LED UV Cold Stamp Mercury
This product, the Inline Unit Petal Type Horizontal Flexographic Print Machinery Narrow Web Label Servo Driven LED UV Cold Stamp Mercury, will be carefully packaged and shipped to ensure its safe arrival at your designated location. The machinery will be securely packed in a sturdy wooden crate, with necessary protection to prevent any damages during transportation. The weight and dimensions of the package will vary depending on the specific model of the machinery. Once the package is ready, it will be shipped via a reputable courier service, with the option for expedited delivery if needed. Upon delivery, please inspect the package for any damages and contact us immediately if necessary. Thank you for choosing our product.

FAQ:

  • Q: What is the brand name of this product?
  • A: The brand name is Supreme.
  • Q: What is the model number of this product?
  • A: The model number is RYW-350/450.
  • Q: Where is this product manufactured?
  • A: This product is manufactured in Wenzhou.
  • Q: Is this product certified?
  • A: Yes, this product is certified with CE.
  • Q: What is the minimum order quantity for this product?
  • A: The minimum order quantity is 1 set.
  • Q: Is the price negotiable for this product?
  • A: Yes, the price is negotiable.
  • Q: How is this product packaged?
  • A: This product is packaged in fumigation wooden box.
  • Q: What is the estimated delivery time for this product?
  • A: The estimated delivery time is 80-120 working days.
  • Q: What are the payment terms for this product?
  • A: The payment terms are TT.
  • Q: What is the supply ability for this product?
  • A: The supply ability is 5 sets per month.







Technical data
Model RYW-350/450
Max unwinding diameter 600mm
Repeat printing length 57T-158T
Max paper width 350mm/450mm
Max printing width 340mm/440mm
Machine body thickness 25mm
Suit for material 30-300gsm paper;
Tension control range 5-100kg
Tension control accurate +-1kg
Gear 1/8CP,teeth space 3.175mm
Print plate thickness 1.14mm
Printing precision +-0.1mm
Double side tape thickness 0.38mm
Print servo motor power 1.3KW+1.8KW
Unwinding and rewinding also traction servo motor power 2.9KW
Machine max speed 150m/min
Air pressure 0.8mpa
Power requirement 380V/3P/50HZ AC
Total power depends client requirement( colors, width, functions)





1. Unwinding unit

• Unwinding magnetic powder automatic tension control system

• Paper break stop device

• Equipped with air gun

2. Automatic web guide system (Arise)

• Equipped with pneumatic paper receiving table

• The paper guide roller is anodized with high hardness

• Using ball screw electric actuator

• Ultrasonic sensor for guiding transfer sensing

• The system can continuously and accurately correct the slight deviation when the paper web moves

• Detection method: edge detection

• Correction accuracy: ±0.1mm

3. In/out paper system

• pressure roller and rubber cooperated to feed paper

• Servo motor controls tension

4. Printing color group

• Pneumatic clutch for anilox roller and printing roller

• Ceramic anilox roller, 1 piece per color (the number is determined by the customer)

• Plate roller, 1 piece per color (the number of teeth is determined by the customer)

• No need to re-adjust the pressure if the anilox roller and doctor blade are replaced

• Stainless steel ink tank

• The plate roller adopts the latest petal structure, the pressure is stable, and the roller can be changed quickly without any tools

• Automatic printing plate cleaning function: After the anilox roll is off the pressure every time the machine stops, the plate roller continues to rotate for 1.5 seconds to transfer the ink on the printing plate to the paper, keeping the printing plate clean.

•Anilox roller rotation function: The Anilox roller will run automatically every time the machine stops to prevent the ink from drying on the surface of the Anilox roller and causing blockage of the screen cells.

• Three-roller gear: cp1/8, made of 20CrMnTi, featuring high wear resistance and long service life

•Anilox roller, plate roller, bottom roller Runout: ≤0.003mm

5. Drying system

• Printing unit UV drying

• The power of the printing unit is synchronized with the host, and the power can be adjusted individually

6. Synchronous strobe color detection unit

• Real-time image capture and detection of printed matter in the printing process, which can move left and right

• The detection position can be set horizontally and vertically

• The detection image can be enlarged for positioning observation

7. Winding unit

• Winding servo motor tension control system

• Equipped with air gun

8. Automatic stop function when the preset output is completed

9. Multi-point speed regulation function can be realized

10. PLC servo control



Inline Unit Petal Type Horizontal Flexographic Print Machinery Narrow Web Label Servo Driven LED UV Cold Stamp Mercury 0Inline Unit Petal Type Horizontal Flexographic Print Machinery Narrow Web Label Servo Driven LED UV Cold Stamp Mercury 1
