PET PVC OPP BOPP SELF ADHESIVE LABELS TWO LAYERS LABELS LAMINATED BOTTOM PAPER AND FILM CRAFT ECT FLEXO PRESS MACHINE

PET PVC OPP BOPP SELF ADHESIVE LABELS TWO LAYERS LABELS LAMINATED BOTTOM PAPER AND FILM CRAFT ECT FLEXO PRESS MACHINE

http://www.youtube.com/@labelturretrewindingmachinery

Optional:

1:cold stamping station

2:film laminating station

3:still image computer with camera

4:Servo motors

5:corona treatment

6:water cooling roller

7:mercury or LED UV

8:Non stop unwinding and rewinding device

This machine is mainly used for 30-300g/m2 web printing. The types of products that can be printed include trademarks, self-adhesive labels, computer forms, bills, aluminum foil, film, milk cardboard, battery film, carton pre-printing, etc. The printer has flexible functional configuration and can be connected to realize double-sided printing, self-adhesive peeling printing, UV varnishing, embossing, die cutting, Laminating, cold stamping, slitting and other processes. It is ideal printing equipment for wine, cigarettes, medicine, cosmetics, milk packs, juice packs, carton packaging (trademarks, boxes, bags, boxes, etc.)

Basic configuration

1. Unwinding unit

• Unwinding magnetic powder automatic tension control system

• Paper break stop device

• Equipped with air gun

2. Automatic web guide system (Taiwan Paursouce)

• Equipped with pneumatic paper receiving table

• The paper guide roller is anodized with high hardness

• Using ball screw electric actuator

• Ultrasonic sensor for guiding transfer sensing

• The system can continuously and accurately correct the slight deviation when the paper web moves

• Detection method: edge detection

• Correction accuracy: ±0.1mm

3. In/out paper system

• pressure roller and rubber cooperated to feed paper

• Servo motor controls tension

4. Printing color group

• Pneumatic clutch for anilox roller and printing roller

• Ceramic anilox roller, 1 piece per color (the number is determined by the customer)

• Plate roller, 1 piece per color (the number of teeth is determined by the customer)

• No need to re-adjust the pressure if the anilox roller and doctor blade are replaced

• Stainless steel ink tank

• The plate roller adopts the latest petal structure, the pressure is stable, and the roller can be changed quickly without any tools

• Automatic printing plate cleaning function: After the anilox roll is off the pressure every time the machine stops, the plate roller continues to rotate for 1.5 seconds to transfer the ink on the printing plate to the paper, keeping the printing plate clean.

•Anilox roller rotation function: The Anilox roller will run automatically every time the machine stops to prevent the ink from drying on the surface of the Anilox roller and causing blockage of the screen cells.

• Three-roller gear: cp1/8, made of 20CrMnTi, featuring high wear resistance and long service life

•Anilox roller, plate roller, bottom roller Runout: ≤0.003mm

5. Drying system

• Printing unit UV drying

• The power of the printing unit is synchronized with the host, and the power can be adjusted individually

6. Synchronous strobe color detection unit

• Real-time image capture and detection of printed matter in the printing process, which can move left and right

• The detection position can be set horizontally and vertically

• The detection image can be enlarged for positioning observation

7. Winding unit

• Winding servo motor tension control system

• Equipped with air gun

8. Automatic stop function when the preset output is completed

9. Multi-point speed regulation function can be realized

10. PLC servo control

About us:

Professionally research and development in Label flexo printing machine, Label die cutting machine and Some other auxiliary equipment, We focus on talents and technological innovation, Adhere to the development strategy of "technical innovation, national brand", making the company a leader in the production line of label machinery.

Honesty, high quality, and service are our business tenet. Forge ahead, pragmatic and efficient are our corporate spirit. We research and manufacture various types of label machines, and welcome all new and old customers and friends to visit!

Because of upgraded and development, above datasheet just for reference, for the newest machinery, please enquiry our company. The finally interpretation is owned by our company

Support and Services:

We provide technical support and services for PET PVC OPP BOPP SELF ADHESIVE LABELS TWO LAYERS LABELS LAMINATED BOTTOM PAPER AND FILM CRAFT ECT FLEXO PRESS MACHINE. Our team of experienced technicians and engineers are available to help you with any questions or issues you may have. We offer a wide range of services such as installation, maintenance, troubleshooting, and repairs. In addition, we offer training and consulting to ensure that your machinery is running at its best.

At our facility, we provide a full range of services for PET PVC OPP BOPP SELF ADHESIVE LABELS TWO LAYERS LABELS LAMINATED BOTTOM PAPER AND FILM CRAFT ECT FLEXO PRESS MACHINE. Our team of technicians and engineers are available to help you with any questions or issues you may have. From installation to maintenance, our team is fully equipped and ready to assist you.

Our goal is to provide the best technical support and services for PET PVC OPP BOPP SELF ADHESIVE LABELS TWO LAYERS LABELS LAMINATED BOTTOM PAPER AND FILM CRAFT ECT FLEXO PRESS MACHINE. Our team of experts is available to answer any questions or concerns you may have. We take pride in providing quality service, and we are committed to ensuring your satisfaction.

Packing and Shipping:

PET PVC OPP BOPP SELF ADHESIVE LABELS TWO LAYERS LABELS LAMINATED BOTTOM PAPER AND FILM CRAFT ECT FLEXO PRESS MACHINE is packaged carefully to ensure it arrives safely and in excellent condition. The machines are fully assembled, and then wrapped in film then packed with the fumigation wooden box.

Machines are shipped via air or sea freight, depending on the customer’s preference.

FAQ:

Q: What is the Minimum Order Quantity of PET PVC OPP BOPP SELF ADHESIVE LABELS TWO LAYERS LABELS LAMINATED BOTTOM PAPER AND FILM CRAFT ECT FLEXO PRESS MACHINE?

A: The Minimum Order Quantity is 1.
